1103D-33TA Industrial Diesel Engine

Perkins

1103D-33TA Industrial Diesel Engine

رقم القطعة: 1000002501

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

1103D-33TA Industrial Diesel Engine

المواصفات

Model1103D-33TA
Series1100 Series
CategoryIndustrial
Power Rating / Maximum Power58 kW (77.8 hp)
Power Rating / Maximum Torque310 Nm @ 1400 rpm (228.6 lb-ft @ 1400 rpm)
Power Rating / Rated Speed2200 rpm
Power Rating / Minimum Power47 kW (63 hp)
Emission Standards / EmissionsUN ECE R96 Stage IIIA
General / Number of Cylinders3 inline
General / Cycle4 stroke
General / Bore105 mm (4.1 in)
General / Stroke127 mm (5 in)
General / Displacement3.3 l (202 in³)
General / Compression Ratio18.23:1
General / AspirationTurbocharged aftercooled
General / Combustion SystemDirect injection
General / Rotation from Flywheel EndAnti-clockwise
General / Cooling SystemLiquid
Engine Dimensions / Length546 mm (21.5 in)
Engine Dimensions / Width586 mm (23 in)
Engine Dimensions / Height826 mm (32.5 in)
Engine Dimensions / Dry Weight276 kg (608.5 lb)
General / Aftertreatment-
