403A-11G Electric Power Diesel Engine

Perkins

403A-11G Electric Power Diesel Engine

رقم القطعة: 1000002605

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

403A-11G Electric Power Diesel Engine

المواصفات

Model403A-11G
Series400 Series
CategoryElectric Power Generation
Emission Standards / EmissionsFuel Optimised
General / Number of Cylinders3 inline
General / Bore77 mm (3 in)
General / Stroke81 mm (3.1 in)
General / Displacement1.1 l (69 in³)
General / Compression Ratio23.0:1
General / AspirationNaturally Aspirated
General / Combustion SystemIndirect Injection
General / Rotation from Flywheel EndAnti-clockwise
General / Cooling SystemLiquid
Total Power Range / Gross Mechanical Output8.6-9.5 kWm
Total Power Range / Typical Electrical Output9-10 kVA (7.2-8 kWe)
Total Power Range / Rated Speed1500 rpm
50 Hz Typical Electrical Output / Prime9 kVA
50 Hz Typical Electrical Output / Standby10 kVA
General / Aftertreatment-
General / Typical Alternator Efficiency86%
General / SwitchableNo
ElectropaK Dimensions / Length775 mm (30.5 in)
ElectropaK Dimensions / Width438 mm (17.2 in)
ElectropaK Dimensions / Height702 mm (27.6 in)
ElectropaK Dimensions / Dry Weight129 kg (284 lb)
