4008-30TAG Electric Power Diesel Engine

Perkins

4008-30TAG Electric Power Diesel Engine

رقم القطعة: 1000021200

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

4008-30TAG Electric Power Diesel Engine

المواصفات

Model4008-30TAG
Series4000 Series
CategoryElectric Power Generation
Emission Standards / EmissionsFuel Optimised
General / Number of Cylinders8 inline
General / Bore160 mm (6.3 in)
General / Stroke190 mm (7.5 in)
General / Displacement30.6 l (1865 in³)
General / Compression Ratio13.6:1
General / AspirationTurbocharged and air-to-air charge cooled
General / Combustion SystemDirect injection
General / Rotation from Flywheel EndAnti-clockwise
General / Cooling SystemLiquid
Total Power Range / Gross Mechanical Output808-1105 kWm
Total Power Range / Typical Electrical Output900 - 1250 kVA (720 - 1000 kWe)
Total Power Range / Rated Speed1500 rpm
50 Hz Typical Electrical Output / Prime900-1125 kVA
50 Hz Typical Electrical Output / Standby1000-1250 kVA
General / Aftertreatment-
General / Typical Alternator Efficiency95%
General / SwitchableNo
ElectropaK Dimensions / Length3468 mm (137 in)
ElectropaK Dimensions / Width2194 mm (86 in)
ElectropaK Dimensions / Height1920 mm (76 in)
ElectropaK Dimensions / Dry Weight4217 kg (9297 lb)
50 Hz Typical Electrical Output / Baseload750-950 kVA
