DCA-15LSX
رقم القطعة: DCA-15LSX
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
DCA-15LSX
المواصفات
| Model | DCA-15LSX |
|---|---|
| Series | Single Phase |
| Category | Generator Sets |
| Fuel Class | diesel |
| Phase | Single Phase |
| Engine Model | Kubota V2203-K3A |
| Emission Standard | Tier 3(Japanese regulation) |
| EN / Model [model] | DCA-15LSX |
| EN / Rated output - Continuous [continuous_power] | 13.0 / 15.0kVA |
| EN / Rated output - Stand by [standby_power] | 14.3 / 16.5kVA |
| EN / Voltage [voltage] | 100～110V/100～120V; 200～220V/200～240V |
| EN / Power Factor [power_factor] | Single Phase 1.0 |
| EN / Engine [engine_model] | Kubota V2203-K3A |
| EN / Fuel [fuel_type] | Diesel |
| EN / Tank Capacity [fuel_tank_capacity] | 62L |
| EN / Dimension L×W×H [dimensions] | 1,540×650×900mm |
| EN / Weight [weight] | 580kg |
| EN / Sound Level (From 7m) - 50Hz [sound_level] | 61dB |
| EN / Sound Level (From 7m) - 60Hz [sound_level] | 64dB |
| EN / Options [options] | Contact your supplier for non-standard requests.; Automatic start and stop device for ATS connection.; Three way valve for connecting external tank; Automatic transfer swich; Exaust Pipe; Salt Corrosion protection |
| EN / Continuous Power (50Hz) [continuous_power] | 13 kVA |
| EN / Continuous Power (60Hz) [continuous_power] | 15 kVA |
| EN / Standby Power (50Hz) [standby_power] | 14.3 kVA |
| EN / Standby Power (60Hz) [standby_power] | 16.5 kVA |
| EN / Phase [phase] | Single Phase |
| JA / 周波数 [frequency] | 50/60Hz |
| JA / 力率 [power_factor] | 1.0 |
| JA / エンジン [engine_model] | クボタ V2203-K3A |
| JA / 燃料 [fuel_type] | 軽油 |
| JA / 燃料タンク [fuel_tank_capacity] | 62L |
| JA / 寸法 全長×全幅×全高 [dimensions] | 1,540×650×900mm |
| JA / 乾燥質量 [dry_weight] | 580kg |
| JA / 整備質量 [operating_weight] | 650kg |
| JA / 騒音値 - 7mdB(A) [sound_pressure_at_distance] | 61/64dB |
| JA / 騒音値 - 騒音指定 [noise_designation] | 超低騒音型 |
| JA / 排出ガス指定 [emission_standard] | 第3次 |
| JA / 定価（税別） [list_price] | ￥2,780,000 |
| JA / 騒音値 - 音響パワーレベル LwA [sound_power_level] | 89dB |
| JA / 出力 [rated_power] | 13/15kVA |
| JA / 電圧 [voltage] | 100/110V |
| JA / 電流 [rated_current] | 130/136A |
| JA / 相数 [phase_count] | 単相（2線式）。単相（3線式）はオプション |
| JA / Rated Power (50Hz) [rated_power] | 13 kVA |
| EN / Emission Regulation [emission_standard] | Tier 3(Japanese regulation) |
| JA / Rated Power (60Hz) [rated_power] | 15 kVA |
