Mobile Generator | 1450kVA / 1158kW | Diesel | (2) 16.1 L

Generac

Mobile Generator | 1450kVA / 1158kW | Diesel | (2) 16.1 L

رقم القطعة: MDE1450

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Mobile Generator | 1450kVA / 1158kW | Diesel | (2) 16.1 L

المواصفات

ModelMDE1450
CategoryMobile Generators
kW/kVA Prime1158 kW / 1447 kVA @60 Hz
Engine(2) Volvo TWD1683GE (Tier 4 Final / EU Stage V)
Spec Sheet / POWER RATING SUMMARY / Standby Power Rating1,271 kW, 1,589 kVA, 60 Hz; 1,127 kW, 1,409 kVA, 50 Hz
Spec Sheet / POWER RATING SUMMARY / Prime Power Rating1,158 kW, 1,447 kVA, 60 Hz; 1,039 kW, 1,299 kVA, 50 Hz
Spec Sheet / ENGINE / General / Make (Model)Volvo TWD1683GE
Spec Sheet / ENGINE / Cooling System / Cooling System TypeWater Cooled
Spec Sheet / ENGINE / General / EPA Emissions ComplianceTier 4 Final
Spec Sheet / ENGINE / Cooling System / Water Pump TypeCentrifugal Pump
Spec Sheet / ENGINE / Cooling System / Fan TypeElectric w/ Inverter
Spec Sheet / ENGINE / Cooling System / Fan Speed: RPMVariable: min 150 - max 1250
Spec Sheet / ENGINE / General / TypeInline
Spec Sheet / ENGINE / Cooling System / Fan Diameter: in (mm)45 (1143)
Spec Sheet / ENGINE / Cooling System / Cooling System Capacity - US galTotal 2 Engines 103 (390)
Spec Sheet / ENGINE / General / Bore: in (mm)5.7 (144)
Spec Sheet / ENGINE / General / Stroke: in (mm)6.5 (165)
Spec Sheet / ENGINE / General / Compression Ratio16:8:1
Spec Sheet / ENGINE / General / Intake Air MethodTurbocharged & Aftercooled
Spec Sheet / ENGINE / Fuel System / Fuel TypeUltra Low Sulfur Diesel
Spec Sheet / ENGINE / Fuel System / FuelASTM D975 D1 & D2
Spec Sheet / ENGINE / Fuel System / Fuel Filtering5 micron
Spec Sheet / ENGINE / Engine Governing / GovernorElectronic
Spec Sheet / ENGINE / Lubrication System / Oil PumpGear Drive (by Transmission)
Spec Sheet / ENGINE / Lubrication System / Oil Filter Type40 Micron
Spec Sheet / ENGINE / Lubrication System / Engine Oil Capacity: qt (L)50 (48)
Spec Sheet / ENGINE / Engine Electrical System / System Voltage: VDC24V
Spec Sheet / ENGINE / Engine Electrical System / Battery - CCA975
Spec Sheet / ENGINE / Engine Electrical System / Battery - V (Qty)12V (4)
Spec Sheet / ENGINE / Engine Electrical System / Ground PolarityNegative (-)
Spec Sheet / STANDARD ALTERNATOR / Make (Model)Mecc Alte ECO40 3L4 C
Spec Sheet / STANDARD ALTERNATOR / Standard ExcitationDER1
Spec Sheet / STANDARD ALTERNATOR / Bearings1
Spec Sheet / STANDARD ALTERNATOR / Field TypeRevolving
Spec Sheet / STANDARD ALTERNATOR / Coupling14
Spec Sheet / STANDARD ALTERNATOR / Insulation Class - RotorClass H
Spec Sheet / STANDARD ALTERNATOR / Prototype Short Circuit TestYes
Spec Sheet / STANDARD ALTERNATOR / Voltage Regulator TypeDigital AVR
Spec Sheet / STANDARD ALTERNATOR / Total Harmonic Distortion (THD)<3.5%
Spec Sheet / STANDARD ALTERNATOR / Quantity of Sensed Phases3
Spec Sheet / STANDARD ALTERNATOR / Telephone Interference Factor (TIF)<40
Spec Sheet / STANDARD ALTERNATOR / Regulation Accuracy (Steady State)0.50%
Spec Sheet / DIMENSIONS AND WEIGHTS / Skid / Dimensions - L×W×H238 (6.0)×96 (2.4)×114 (2.9)
Spec Sheet / DIMENSIONS AND WEIGHTS / Skid / Weight (Operating)41,076 (18,631)
AlternatorMecc Alte ECO40 3L4 C
Standby Power1,271 kW, 1,589 kVA, 60 Hz; 1,127 kW, 1,409 kVA, 50 Hz
Spec Sheet / ENGINE / General / Displacement: in³ (L)983.8 (16.1)
Spec Sheet / ENGINE / General / Cylinders - Qty6
Spec Sheet / STANDARD ALTERNATOR / Poles - Qty4
Spec Sheet / STANDARD ALTERNATOR / Insulation Class - StatorClass H
Spec Sheet / ENGINE / Cooling System / Belt1.85/1
Spec Sheet / ENGINE / Fuel System / Double Fuel Pre-filter w/Water10 micron + 30 micron
Spec Sheet / ENGINE / Separator / Injector TypeUnit Injector - Delphi
Spec Sheet / POWER RATINGS / 60Hz / Standby: kW/kVA (A)1,271 / 1,589
Spec Sheet / POWER RATINGS / 60Hz / Prime: kW/kVA (A)1,158 / 1,447
Spec Sheet / POWER RATINGS / 50Hz / Standby: kW/kVA (A)1,127 / 1,409
Spec Sheet / POWER RATINGS / 50Hz / Prime: kW/kVA (A)1,039 / 1,299
