3812 Gooseneck ADT-Pulled Scraper Pan

Name: 3812 Gooseneck ADT-Pulled Scraper Pan
Brand: John Deere
SKU: JOHNDEERE-51A0T

رقم القطعة: JOHNDEERE-51A0T

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

3812 Gooseneck ADT-Pulled Scraper Pan

Struck	19.19 m (25.1 cu. yd.)
C Height	3556 mm (140.00 in.) (11 ft. 8 in.)
Model	3812 Gooseneck
Base Code	51A0T
Division	tractors
Product Family	scraper-systems
A Length	11 506 mm (452.99 in.) (37 ft. 9 in.)
Hitch	32%
F E A T U R E S	3 8 1 2 A D T - P U L L E D S C R A P E R P A N
Heaped	29.05 m (38.0 cu. yd.)
Approximate Shipping Weight	22 180 kg (48,899 lb.)
Wheels	68%
Flow	314.16 lpm (83 gpm)
System Pressure	28 000 kPa (4,061.06 psi)
B Width	4242 mm (168.00 in.) (14 ft. 0 in.)
D Blade — Bowl Up	617 mm (24.29 in.)
E Floor — Bowl Up	587 mm (23.11 in.)
F Bowl Width	3912 mm (154.02 in.) (12 ft. 10 in.)
G Bowl Length	3619 mm (142.48 in.) (11 ft. 10 in.)
s Heavy-duty (HD)	6-in. drop-center cutting edge s Scraper controls kit (includes bowl camera)*
