895-3
رقم القطعة: KOMATSU-895-3
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
895-3
المواصفات
| Fuel tank (L) | 245 |
|---|---|
| Voltage | 24 V |
| Power (HP) | 287 @ 1,850 rpm (EU Stage V/Tier 4F), 282 @ 1,850 rpm (Stage 2), 259 @ 1,900 rpm (MAR-1) |
| Power (kW) | 214 @ 1,850 rpm (EU Stage V/Tier 4F), 210 @ 1,850 rpm (Stage 2), 193 @ 1,900 rpm (MAR-1) |
| Gross load (kg) | 20,000 |
| Gross load (lbs) | 44,092 |
| Tractive force (kN) | 262 |
| Tractive force (lbf) | 59,000 |
| Driving speed (mph) | 0-14.3 |
| Stroke volume (L) | 7.4 |
| Torque (Nm) | 1,280 @ 1,500 rpm (EU Stage V/Tier 4F/Stage 2), 1,000 @ 1,500 rpm (MAR-1) |
| Torque (ft-lbs) | 944 @ 1,500 rpm (EU Stage V/Tier 4F/Stage 2), 738 @ 1,500 rpm (MAR-1) |
| Reach (ft) | 24.6 / 27.9 / 32.8 |
| Reach (m) | 7.5 / 8.5 / 10 |
| Rotator | G121/GT151/GT181/GX |
| Grapple | We offer a wide selection of grapples, please contact your sales representative for more information. |
| Flow (L) | 409 @ 1,950 rpm |
| Flow (US gal) | 108 @ 1,950 rpm |
| Approximate weight (kg) | 6WD: 21,850 , 8WD: 24,830 |
| Approximate weight (lbs) | 6WD: 48,170 , 8WD: 54,740 |
| Width (mm) | With 780/50 x 28,5 tires: 3,160 mm |
| Width (ft) | With 780/50 x 28,5 tires: 10 ft 4 in |
| Ground clearance, at steering coupling (mm) | 8WD: 790 |
| Ground clearance, at steering coupling (ft) | 8WD: 2 ft. 7 in |
| Battery capacity | 2 x 185 Ah |
| Max tractive effort (kN) | 262 |
| Max tractive effort (lbf) | 59,000 |
| Driving speed (km/h) | 0 - approx. 23 |
| Power (HP) (Engine) | 287 HP DIN @ 1,850 rpm (EU Stage V/Tier 4F), 282 @ 1,850 rpm (Stage 2), 259 @ 1,900 rpm (MAR-1) |
| Power (kW) (Engine) | 214 kW DIN @ 1,850 rpm (EU Stage V/Tier 4F), 210 @ 1,850 rpm (Stage 2), 193 @ 1,900 rpm (MAR-1) |
| Type | AGCO Power, 6-cylinder diesel engine with turbo and intercooler. EU Stage V, Tier 4F, MAR-1 and Stage 2. |
| Stroke volume (gal) | 1.95 |
| Fuel tank (gal) | 64.7 |
| Crane | Komatsu 165F/205F |
| Gross slewing torque (lbf-ft) | 32,010 / 38,280 |
| Gross slewing torque (kNm) | 43.4 /51.9 |
| Gross lifting torque (kNm) | 165 / 205 |
| Gross lifting torque (lbf-ft) | 121,698 / 151,200 |
| Generator | 2 x 100 A |
| Bunk area (sq.ft) | 62 - 79.6 |
| Bunk area (m²) | 5.8-7.4 |
| Length total (ft) | 36 ft. 1 in (with shortest rear frame) |
| Length total (mm) | 11,000 (with shortest rear frame) |
| Length front axle to middle joint (ft) | 7 |
| Length front axle to middle joint (mm) | 2,150 |
| Length middle joint to rear axle (mm) | 3,900 |
| Transport height (with hoses and tire compression) (in) | 165F: 13 ft 2 in, 205F: 13 ft 1 in |
| Transport height (with hoses and tire compression) (mm) | 165F: 4,010 mm, 205F: 3,980 mm |
| Length middle joint to rear axle (ft) | 12 ft. 8 in |
