TL755D harvester

Komatsu

TL755D harvester

رقم القطعة: KOMATSU-TL755D-HARVESTER

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

TL755D harvester

المواصفات

Horsepower (HP)350
Horsepower (kW)261
Engine modelCummins L9 Performance
AspirationeVGT, after cooled, cooled EGR
Number of cylinders6
Piston displacement (L)8.9
Piston displacement (in^3)540
Fan drive typeHybrid, variable speed, auto reverse
Fuel tank (US gal)256
Fuel tank (L)969
Track typeGrease sealed
Parking brakeOil bath, multi disc, spring applied, hybrid release
Swing speed (rpm)6.6
Bore (mm)114
Bore (in)4.49
Stroke (in)5.86
Stroke (mm)145
Track frameHD boxed structure, with shoe support
Drive methodHydrostatic
Swing torque (kN/m)87.6
Engine typeWater cooled, 4-cycle, XPI fuel injection
Tractive effort (kgf)Up to 46,984
Tractive effort (lbf)Up to 103,583
Lifting capacity (kg)Up to 6,758 at 6.1 m
Car bodyHD boxed frame structure with flat bottom, storage trunk, integrated fuel tank
Number of shoes/links (per side)48
Track rollers (per side)10
Peak torque (Nm)1561
Peak torque (lbs-ft)1151
Cooling system (gal)13.5
Cooling system (L)51
Engine oil pan (L)6.25
Engine oil pan (gal)23.6
DEF (gal)15
DEF (L)56.8
Swing torque (lbs-ft)64,608
Swing brakeOil bath, multi disc, spring applied, hybrid release
Peak horsepower (kW)261
Peak horsepower (HP)350
