FH70-2
رقم القطعة: KOMATSU-FH70-2
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
FH70-2
المواصفات
| Tire type | Pneumatic |
|---|---|
| Power type | Diesel |
| Capacity (kg) | 7 000 - 8 000 |
| Capacity (lbs) | 15,400 - 18,000 |
| Hydraulic oil capacity (gal) | 35.1 |
| Hydraulic oil capacity (L) | 133 |
| Relief Pressure - attachment (psi) | 2,495 |
| Service weight (kg) | 9 710 |
| Service weight (lbs) | 21,407 |
| Axle loading - loaded front (lbs) | 32,860 |
| Axle loading - loaded front (kg) | 14 905 |
| Axle loading - loaded rear (kg) | 1 805 |
| Axle loading - loaded rear (lbs) | 3,979 |
| Axle loading - unloaded front (lbs) | 9,028 |
| Axle loading - unloaded front (kg) | 4 095 |
| Axle loading - unloaded rear (lbs) | 12,379 |
| Axle loading - unloaded rear (kg) | 5 615 |
| Maximum gradeability (%) | 29 |
| Service brake, operation/control | Foot/Hydraulic |
| Parking brake, operation/control | Hand/Mechanical |
| Steering type | FHPS |
| Operation type | Sit Down |
| Wheelbase (mm) | 2 300 |
| Wheelbase (in) | 90.6 |
| Height overhead guard (mm) | 2 525 |
| Height overhead guard (in) | 99.4 |
| Length to fork face (in) | 141.3 |
| Length to fork face (mm) | 3 590 |
| Overall width at drive tires (in) | 80.7 |
| Overall width at drive tires (mm) | 2 050 |
| Forks, thickness x width x length (mm) | 65 x 150 x 1 220 |
| Forks, thickness x width x length (in) | 2.6 x 5.9 x 48.0 |
| Ground clearance, center of wheelbase (mm) | 305 |
| Ground clearance, center of wheelbase (in) | 12 |
| Ground clearance under mast (mm) | 9.3 |
| Ground clearance under mast (in) | 235 |
| Turning radius, outside (in) | 131.9 |
| Turning radius, outside (mm) | 3 350 |
| Length, with standard forks (mm) | 4 810 |
| Length, with standard forks (in) | 189.4 |
| Mast height - extended (mm) | 4 350 |
| Mast height - extended (in) | 171.3 |
| Mast height - lowered (in) | 101.8 |
| Mast height - lowered (mm) | 2 585 |
| Tire type details | Pneumatic |
| Number of wheels, front/rear | 4x/2 |
| Tire size - front | 8.25 – 15-14PR |
| Tire size - rear | 8.25 – 15-14PR |
| Tread - front (in) | 60.6 |
| Tread - front (mm) | 1 540 |
| Tread - rear (mm) | 1 640 |
| Tread - rear (in) | 64.6 |
| Transmission | Hydrostatic |
| Maximum torque (SaE net)(Nm) | 68.6 Nm @ 1,400 rpm |
| Rated output (SaE Net) (HP) | 66.4 |
| Rated output (SaE Net) (kW) | 48.6 |
| Engine manufacturer / model | Komatsu SAA4D95LE-6-C |
| Fuel tank capacity (L) | 177 |
| Fuel tank capacity (US gal) | 46.8 |
| Number of cylinders / Displacement (cm^3) | 3 260 |
| Number of cylinders / Displacement (in^3) | 4 / 199 |
| Tilting angle, forward/backward (deg) | 6 / 12 degrees |
| Load distance, front axle to fork face (in) | 24 |
| Load distance, front axle to fork face (mm) | 600 |
| Rated capacity (lbs) | 15,400 |
| Rated capacity (kg) | 7 000 |
| Rated load center (in) | 24 |
| Rated load center (mm) | 600 |
| Relief Pressure - attachment (MPa) | 17.2 |
| Maximum drawbar pull (fpm) | 10,049 |
| Maximum drawbar pull (kN) | 44.7 |
| Standard free lift (in) | 8.7 |
| Standard lift height (in) | 118.1 |
| Aisle width for L1 200 x W800 pallet (in) | 211.8 |
| Aisle width for L1 200 x W800 pallet (mm) | 5 380 |
| Aisle width for L1000 x W1200 pallet (in) | 211.8 |
| Fork carriage class (in) | Class 4 / 66.5 |
| Aisle width for L1000 x W1200 pallet (mm) | 5 380 |
| Travel speed, loaded (mph) | 14.0 |
| Travel speed, loaded (kph) | 22.5 |
| Travel speed, unloaded (kph) | 23.5 |
| Travel speed, unloaded (mph) | 14.6 |
| Lifting speed, loaded (fpm) | 84.6 |
| Lifting speed, loaded (mm/sec) | 430 |
| Lifting speed, unloaded (mm/sec) | 500 |
| Lifting speed, unloaded (fpm) | 98.4 |
| Loweringspeed, loaded (mm/sec) | 480 |
| Lowering speed, loaded (fpm) | 94.5 |
| Loweringspeed, unloaded (mm/sec) | 500 |
| Lowering speed, unloaded (fpm) | 98.4 |
| Standard free lift (mm) | 220 |
| Standard lift height (mm) | 3 000 |
| Fork carriage class (mm) | Class 4 / 1 690 |
