14CM27
رقم القطعة: KOMATSU-14CM27
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
14CM27
المواصفات
| Ground clearance (in) | 13.75 |
|---|---|
| Ground clearance (mm) | 349 |
| Conveyor width (in) | 38 |
| Conveyor width (mm) | 965 |
| Tram speed (m/min) | 5 - 26 |
| Ground pressure (kPa) | 225 |
| Ground pressure (psi) | 33 |
| Weight (kg) | 72 500 |
| Weight (lbs) | 160,000 |
| Cutter head diameter (in) | 44 |
| Maximum cutting height (in) | 134 |
| Maximum cutting height (mm) | 3 400 |
| Minimum cutting height (in) | 39 |
| Minimum cutting height (mm) | 1 000 |
| Total power (HP) | 885 |
| Total power (kW) | 660 |
| Cutter head design | Solid head |
| Cutter head diameter (mm) | 1 120 |
| Tram speed (ft/min) | 15 - 85 |
| Dust collector (kW) | 22 or 30 |
| Cutter (HP) | 268 |
| Dust collector (HP) | 30 or 40 HP @ 60 Hz, 25 or 35 HP @ 50 Hz |
| Cutter (kW) | 220 |
| Pump (HP) | 54 |
| Pump (kW) | 40 |
| Gathering head (kW) | 50 |
| Gathering head (HP) | 67 |
| Traction (HP) | 80 |
| Traction (kW) | 60 |
| General footnote | Total power does not include dust collector fan |
| Recommended operating range (mm) | 1 525 - 2 135 |
| Recommended operating range (in) | 52 |
