WX07
رقم القطعة: KOMATSU-WX07
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
WX07
المواصفات
| Operating weight (kg) | 22 340 |
|---|---|
| Operating weight (lbs) | 49,251 |
| Bucket capacity (m^3) | 3.1 |
| Bucket capacity (yd^3) | 4 |
| Batteries | 2 x 12V |
| Alternator | 24V/120A Prestolite |
| Transmission | Dana TE14 |
| Fuel tank capacity (L) | 243 |
| Fuel tank capacity (US gal) | 64 |
| Tramming capacity (kg) | 7 000 |
| Tramming capacity (lbs) | 15432 |
| Engine rated power (standard)(HP) | 215 |
| Engine rated power (standard)(kW) | 160 |
| Starter | 24V heavy duty |
| Driving and working lights | 8 forward / 3 rear |
| Total loaded weight (lbs) | 64,683 |
| Total loaded weight (kg) | 29 340 |
| Front and rear frames | Welded steel box construction |
| Material | A572 GR50 (CSA G40.21-50W) |
| Tires | Bias L5S or Radial |
| Front and rear | Dana 17D |
| Brakes | Spring applied, hydraulic release |
| Front axle (kg) | 20 244 |
| Front axle (lbs) | 44,630 |
| Rear axle (kg) | 9 096 |
| Rear axle (lbs) | 20,053 |
| Raising time (s) | 5.95 |
| Lowering time (s) | 3.45 |
| Height to top of canopy (in) | 85.4 |
| Height to top of canopy (mm) | 2 169 |
| Engine (standard) | Cummins QSB 6.7, EPA Tier 3, MSHA/CANMET |
| Oscillation angle (deg) | +/- 6 |
| Rollback time (s) | 2.45 |
| Output (standard)(HP) | 215 HP @ 2,100 rpm |
| Front axle (kg) (Weights) | 9 639 |
| Front axle (lbs) (Weights) | 21,250 |
| Rear axle (kg) (Weights) | 12 701 |
| Rear axle (lbs) (Weights) | 28,001 |
| Air filtration | Donaldson (dry type) |
| Hydraulic breakout force lift (lbs) | 31,447 |
| Powertrain exhaust system | DOC |
| Hydraulic breakout force lift (kg) | 14 264 |
| Converter | Dana C3000 series |
| Hydraulic breakout force tilt (lbs) | 30,082 |
| Shifting | Powershift with auto and manual modes |
| Hydraulic breakout force tilt (kg) | 13 645 |
| Speeds | 4 forward / 4 reverse |
| SAE breakout force (lbs) | 27,816 |
| Differentials | LSD front axle, no spin rear axle |
| Size (in) | 17.50 x 25 |
| SAE breakout force (kg) | 12 617 |
| Dump motion time (s) | 2 |
| SAE static tipping load (kg) | 21 258 |
| SAE static tipping load (lbs) | 46,866 |
| Bucket volume (m^3) | 3.1 |
| Bucket volume (y^3) | 4 |
| Lock-up | Yes |
| Cabin lights | 3 interior lights (LED) |
