951XC-2
رقم القطعة: KOMATSU-951XC-2
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
951XC-2
المواصفات
| Fuel tank (L) | 466 |
|---|---|
| Voltage | 24 V |
| Power (HP) | 335 @ 1,850 rpm (EU Stage V, Tier 4F), 287 @ 1,850 rpm (MAR-1) |
| Power (kW) | 250 @ 1,850 rpm (EU Stage V, Tier 4F), 214 @ 1,850 rpm (MAR-1) |
| Driving speed (mph) | 0 - approx. 15.6 |
| Stroke volume (L) | 7.5 |
| Torque (Nm) | 1,450 @ 1,500 rpm (EU Stage V, Tier 4F), 1,280 @ 1,500 rpm (MAR-1) |
| Torque (ft-lbs) | 1,069 @ 1,500 rpm (EU Stage V, Tier 4F), 944 @ 1,500 rpm (MAR-1) |
| Approximate weight (kg) | From 23,775 |
| System pressure (psi) | 4,061 |
| Approximate weight (lbs) | From 52,414 |
| System pressure (bar) | 280 |
| Width (mm) | With 710/55x26.5 tyres: 2,980 |
| Width (ft) | With 710/55x26.5 tyres: 9 ft 9 in |
| Battery capacity | 2 x 185 Ah |
| Max tractive effort (kN) | 243 |
| Max tractive effort (lbf) | 54,626 |
| Driving speed (km/h) | 0 - approx. 25 |
| Type | AGCO Power 75FSTN-D5, 6-cylinder diesel engine with turbo and intercooler |
| Stroke volume (gal) | 1.98 |
| Fuel tank (gal) | 123 |
| Gross slewing torque (lbf-ft) | 44,253 |
| Gross slewing torque (kNm) | 60 |
| Gross lifting torque (kNm) | 285 |
| Gross lifting torque (lbf-ft) | 210,205 |
| Generator | 200 A |
| Length total (ft) | 26 ft. 3 in |
| Length total (mm) | 8,005 |
| Length front axle to middle joint (ft) | 6 ft 4 in |
| Length front axle to middle joint (mm) | 1,930 |
| Length middle joint to rear axle (mm) | 2,150 |
| Length middle joint to rear axle (ft) | 7 ft. 1 in |
| Model and reach (ft) | 280H: 33 ft. 9.5 in / 36 ft. 1 in |
| Model and reach (m) | 280H: 10.3 / 11 |
| Transport height with tire compression (mm) | Straight cab: 3,960 - 4,015 (depending on options). Transport position (cab max rear tilt, crane forward, light ramp tilted): 3,940 |
| Transport height with tire compression (ft) | Straight cab: 13 ft -13 ft 2 in (depending on options). Transport position (cab max rear tilt, crane forward, light ramp tilted): 12 ft 11 in |
| Available heads | C124, S132, C144, S172, C164, 370E, S162E |
| Ground clearance (at stearing joint) (mm) | 710 |
| Ground clearance (at stearing joint) (ft) | 2 ft. 4 in |
| Flow (l/min) | 485 @ 1,470 rpm |
| Flow (gal/min) | 128 @ 1,470 rpm |
| Max tractive effort (Ibf) | 54,626 |
