BA96C Angle Broom Compact Equipment Attachment

Name: BA96C Angle Broom Compact Equipment Attachment
Brand: John Deere
SKU: JOHNDEERE-0304KV

رقم القطعة: JOHNDEERE-0304KV

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

BA96C Angle Broom Compact Equipment Attachment

Model	BA96C Angle Broom
Base Code	0304KV
Division	construction-equipment
Product Family	construction-attachments
Weight	460 kg (1,010 lb.)
Hydraulic Flow / Minimum	57 L/min. (15 gpm)
Hydraulic Flow / Maximum	95 L/min. (25 gpm)
	
Sweeping Angle	±30 deg.
Overall Length / Straight	1740 mm (69 in.)
Overall Length / Angled at 30 deg.	2180 mm (86 in.)
Overall Width / Straight	2940 mm (116 in.)
Overall Width / Angled at 30 deg.	2760 mm (109 in.)
Sweeping Width / Straight	2440 mm (96 in.)
Sweeping Width / Angled at 30 deg.	2110 mm (83 in.)
Sweeping Width / Overall Height	1010 mm (40 in.)
Sweeping Width / Brush Diameter	810 mm (32 in.)
Sweeping Width / Core Diameter	250 mm (10 in.)
Sweeping Width / Number of Wafers	47
Hydraulic Flow / Motor Pressure Relief Setting	17 000 kPa (2,500 psi)
Hydraulic Flow / Brush Coverage	180 deg.
Roof-Mounted Water Tank / Water-Tank Capacity	114 L (30 gal.)
Roof-Mounted Water Tank / Pump Flow	6.8 L/min. (1.8 gpm)
Roof-Mounted Water Tank / Vehicle Compatibility	330 P-Tier and 334 P-Tier SSLs; 331 P-Tier, 333 P-Tier, and 335 P-Tier CTLs; 184 G-Tier, 204 G-Tier, 244 P-Tier*,
