Z515E ZTrak™ Mower

Name: Z515E ZTrak™ Mower
Brand: John Deere
SKU: JOHNDEERE-5620GX

رقم القطعة: JOHNDEERE-5620GX

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Z515E ZTrak™ Mower

Model	Z515E
Base Code	5620GX
Division	mowers
Product Family	residential-lawn-mowers
ENGINE / Displacement	44.2 cu in. (724 cc)
ENGINE / Cylinders	V-twin
ENGINE / Cooling method	Air
SLOPE / Slope Operating Limit**	15 degrees
ELECTRICAL SYSTEM / Battery voltage	12 Volt with charge port
DRIVE TRAIN / Forward speed, mph (km/h)	0-8 (0-12.9)
DRIVE TRAIN / Reverse speed, mph (km/h)	0-4 (0-6.4)
DRIVE TRAIN / Control adjustment	2 height / 18 positions
TIRES / Front caster tires	13x6.5-6
TIRES / Drive tires***	22x9.5-10
SEAT / Seat back height	18" (45.7 cm) medium-back
MOWER DECK / Width of cut	48/54/60 in. AccelDeep
MOWER DECK / Type	Side Discharge
MOWER DECK / Mower deck material	10 gauge, 0.135 in. (3.4 mm)
DIMENSIONS / Overall length, in. (cm)	76.9 (195.3)
DIMENSIONS / ROPS	Yes Bumper-to-bumper 4 year/300 hour
ENGINE / Power*	24 hp* (17.9kW)
ENGINE / Model No.	44 PXi
ENGINE / Replaceable oil filter	Yes
FUEL/POWER SYSTEM / Type	Gas
FUEL/POWER SYSTEM / Fuel tank capacity	4.5 gal (17 L)
FUEL/POWER SYSTEM / Fuel fill diameter	3 in. (7.6 cm)
FUEL/POWER SYSTEM / Fuel/Energy Indicator	Electric gauge and sight window
ELECTRICAL SYSTEM / Hourmeter	Standard
DRIVE TRAIN / Transmission	Tuff Torq TZT7-U w/1-in. (2.54 cm) axles
TIRES / Rubber floor mat	Optional Kit
SEAT / Armrests	Standard
SEAT / Fore-aft adjustment	4 in. (10.2 cm) while seated
MOWER DECK / PTO	Foot lift Electric , 105lb-ft
MOWER DECK / Drive	V-Belt
DIMENSIONS / Width, in. (cm)	49.2 (125)
DIMENSIONS / Height, in. (cm)	47.6 (121)
DIMENSIONS / Weight (with mower and fuel), lb (kg)	780-808 (354-366)
