X570 (48-in. Deck) Lawn Tractor

John Deere

X570 (48-in. Deck) Lawn Tractor

رقم القطعة: JOHNDEERE-5348M

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

X570 (48-in. Deck) Lawn Tractor

المواصفات

ModelX570 (48-in. Deck)
Base Code5348M
Divisionmowers
Product Familyresidential-lawn-mowers
ENGINE / Displacement44.3 cu in. (726 cc)
Dimensions / Height45 in. (114.3 cm)
ENGINE / Model numberFR730V iTorque™ Power System
SLOPE / Slope Operating Limit**15 degrees
FUEL SYSTEM / Fuel tank capacity4.4 U.S. gal. (16.7 L)
LIFT SYSTEM / TypeHydraulic
ENGINE / CoolingAir
DIMENSIONS / Overall Length75 in. (191 cm) / 79 in. (201 cm)
DIMENSIONS / Wheelbase51.2 in. (130 cm)
TRANSMISSION / Forward Speed0-7.2 mph (0-11.6 km/h)
TRANSMISSION / Reverse Speed0-5.2 mph (0-8.4 km/h)
TIRES / Front15x6.5-8 / 16x6.5-8
TIRES / Rear24x12-12 / 24x12-12
ENGINE / Engine Power24 hp* (17.9 kW)
ENGINE / GovernorMechanical
ENGINE / Cylinder ConfigurationV-twin
ENGINE / Electrical System12 volts, 12 amp regulated
DASH DISPLAY / Fuel GaugeYes
TRANSMISSION / STEERING:Low effort, 2-wheel steer / Power, 2-wheel steer
TRANSMISSION / Tilt WheelNo
TRANSMISSION / Front AxleCast iron
TRANSMISSION / TURNING RADIUS16 in. (40.6 cm) / 22 in. (55.9 cm) 23 in. (58 cm) w/48A Mower or 20 in. (51 cm)
SEAT / Style15 in. (38.1 cm) open back with grasp / w/54A Mower / 24 in. (61 cm) w/54A Mower 21 in. (53.3 cm) cut and sewn
TIRES / TypeTurf (front and rear) / Turf (front), and Heavy-Duty All-Purpose (rear)
DIMENSIONS / Min. Storage Width (Deflector Up)53.6 in. (136 cm) w/48 in. Accel Deep or 59.4 in. (151 cm) w/54 in. Accel Deep
DIMENSIONS / Weight, Tractor (no fuel) and Mower748 lb (339 kg) w/48 in. Accel Deep, 756 lb (343 kg) w/54 in. Accel Deep / 787 lb (357 kg) w/54 in. Accel Deep
MOWER DECK OPTIONS / Cutting Width /Blades48 in. (122 cm) 3 blades or 54 in. (137 cm) 54 in. Accel Deep 48 in. Accel Deep™ or 54 in. Accel Deep / 3 blades / 54 in. (137 cm) 3 blades
MOWER DECK OPTIONS / BUMPER-TO-BUMPER4 year/500 hours
