LR2196 Landscape Rake

Name: LR2196 Landscape Rake
Brand: John Deere
SKU: JOHNDEERE-1203XF

رقم القطعة: JOHNDEERE-1203XF

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

LR2196 Landscape Rake

Model	LR2196
Base Code	1203XF
Division	tractors
Product Family	tractor-attachments-and-implements
Duty Economy Standard Standard	Medium
Tractor PTO horsepower (maximum) 25 hp (18.6 kW) 19 to 40 hp (14.2 - 29.8 kW) 19 to 40 hp (14.2 - 29	27 to 55 hp (20.1 - 41.0 kW)
Hitch Limited Cat. 1, Cat. 0 optional Category 1 (iMatch compatible) Category 1 (iMatch compatible)	Category 1 (iMatch compatible)
Working width 60 in. (152.4 cm) 72 in. (182.9 cm) 84 in. (213.4 cm)	96 in. (243.8 cm)
Raking positions, forward 0, 15, 30 degrees each side 0, 15, 30 degrees each side 0, 15, 30 degrees	0, 15, 30 degrees each side
Raking positions, reverse 0, 15 degrees each side 0, 15 degrees each side 0, 15 degrees each side	0, 15 degrees each side
Pivot 360 degrees 360 degrees 360 degrees	360 degrees
(30) .31 x 1 in. (7.9 x 25.4 mm) (36) .31 x 1 in. (7.9 x 25.4 mm) (42) .31 x 1 in. (7.9 x 25.4 mm)	(48) .31 x 1 in. (7.9 x 25.4 mm)
Tines / spring steel spring steel spring steel	spring steel
Tines / 3 x 3 in. (76.2 x 76.2 mm) 3 x 3 in. (76.2 x 76.2 mm) 3 x 3 in. (76.2 x 76.2 mm)	4 x 4 in. (101.6 x 101.6 mm)
Frame / tubular steel tubular steel tubular steel	steel
Frame / Parking stand Standard Standard Standard	Standard
Frame / Weight 168 lb. (76.2 kg) 200 lb. (90.7 kg) 221 lb. (100.2 kg)	332 lb. (150.6 kg)
Frame / Warranty* 1 year 1 year 1 year	1 year
