John Deere

6120E Cab Tractor

Name: 6120E Cab Tractor
Brand: John Deere
SKU: JOHNDEERE-333FP

رقم القطعة: JOHNDEERE-333FP

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

6120E Cab Tractor

المواصفات

Model	6120E Cab
Base Code	333FP
Division	tractors
Product Family	utility-tractors
ENGINE / Type	Diesel, in-line, 4-cylinder, wet-sleeve cylinder liners with 4 valves-in-head
ENGINE / Displacement	275 cu. In. (4.5L)
ENGINE / Lubrication	Full-pressure, full-flow filtration with bypass
Cylinders	4
ENGINE / Rated speed	2,200 rpm
ENGINE / Filter, engine air	Dual stage with aspiration
ENGINE / Compression ratio	16.8:1
ENGINE / Bore and stroke	4.17 in. (106 mm) x 5.00 in. (127 mm)
ENGINE / Filter, oil	Replaceable cartridge style oil filter
WHEELBASE / MFWD	96.5 in. (2450 mm)
DIFFERENTIAL LOCK / HYDRAULIC SYSTEM (type)	Open center, gear driven
DIFFERENTIAL LOCK / Selective control valves	2 Mechanical SCVs Standard; 3 Mechanical SCVs Optional
DIFFERENTIAL LOCK / Maximum pressure	2,828 psi (19,500 kPa)
4.5 L Engine	PowerTech PWL
Emission Level	Final Tier 4
Engine HP ‡	120 (89.5 kW)
PTO HP	102 (76.1 kW)
Injection	HPCR electronic
Rated Engine Speed (RPM) ‡ Manufacturer’s estimate of power (ISO) per 97/68/EC. 6	2,200
POWER * estimated / Rated PTO power (hp SAE) at engine speed (2100 erpm)	102 hp (76 kW)
POWER * estimated / Rated Engine power hp (hp ISO) at 2200 engine rpm (97/68EC)*	120 hp (88 kW)
POWER * estimated / Engine Peak Torque (Nm) (xx% @ 1600rpm)	494 N-m (364 lb.-ft)
POWER * estimated / Constant Power Range (rpm)	1800 - 2200 rpm
ENGINE / Manufacturer (US EPA Interim Tier4/EU Stage IIIb)	PowerTech™ PWL (B20 Diesel Compatible)
AXLES / 2WD – tread range 60.4 to 80.4 in. (1533 to 2043 mm)	Optional
DRAWBAR / PTO Speed @ Engine RPM	540 PTO @ 2085 Engine rpm or 1000 PTO @ 2067 Engine rpm
WHEELBASE / Max Payload Capacity	17636 lb (8000 kg)
ENGINE / Aspiration (US EPA Interim Tier4/EU Stage IIIb)	Wastegate turbocharger with air-to-air aftercooling and cooled exhaust gas recirculation
TRANSMISSION / 12F/12R Top Shaft Synchronized (TSS) Transmission w/	Standard
PowrReverser (30K) / 24F/12R Top Shaft Synchronized (TSS) Transmission w/ PowrReverser and Hi Lo (40	Option
AXLES / Rear Axle Final Drive	Inboard planetary
AXLES / Rear Axle - Flange	Standard
AXLES / MFWD - tread range 59.7 to 79.4 in. (1516 to 2016 mm)	Standard
DIFFERENTIAL LOCK / Front Axle - 2WD	N/A
DIFFERENTIAL LOCK / Front Axle - MFWD	Limited Slip
DIFFERENTIAL LOCK / Rear Axle - Full-Locking mechanical	Standard
DIFFERENTIAL LOCK / Main pump, axial piston (displacement)	36.5 cc
DIFFERENTIAL LOCK / Rated flow (@ 90% Advertised Efficiency)	20 US gpm/75.7 lpm
DIFFERENTIAL LOCK / Available flow at a single SCV 3-POINT HITCH (rear) - Electrohydraulic Sensing	20 US gpm/75.7 lpm
DIFFERENTIAL LOCK / Category 2 (5500 lbs (2500 kg) Standard Lift @ 610mm behind hitchpoint)	Standard
DIFFERENTIAL LOCK / Category 2 (7300 lbs (3318 kg) Heavy Duty Lift @ 610mm behind hitchpoint)	Optional
DIFFERENTIAL LOCK / Draft Sensing	Optional
DRAWBAR / Cat 2 1000 kg (2205 lb.) - 1250 kg (2756 lb.) Maximum Vertical Load dependent on drawbar p	Standard
DRAWBAR / Cat 2 1200 kg (2645 lb.) - 1900 kg (4189 lb.) Maximum Vertical Load dependent on drawbar p	Optional
DRAWBAR / PTO (power take off)	Independent
DRAWBAR / 1-3/8 in., 540/1000 reversible shaft	Standard
WHEELBASE / 2WD	96.7 in. (2456 mm)
WHEELBASE / Max Ballast Level	14250 lb (6464 kg)
