John Deere

1023E Sub-Compact Tractor

Name: 1023E Sub-Compact Tractor
Brand: John Deere
SKU: JOHNDEERE-0253LV

رقم القطعة: JOHNDEERE-0253LV

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

1023E Sub-Compact Tractor

المواصفات

Model	1023E
Base Code	0253LV
Division	tractors
Product Family	compact-tractors
ENGINE / Type	Yanmar 3TNM74F-CJT
ENGINE / Displacement	60.6 cu. in. (993 cc)
ENGINE / Battery Power	500 CCA
HYDRAULICS / Pump Type	Gear
TRANSMISSION / Forward/Reverse Control	Twin Touch Pedals
TRANSMISSION / Final Drive	Spur gear
TRANSMISSION / Brakes	Wet disk, left-hand pedal
POWER TAKE-OFF (PTO) / PTO Type	Independent
3-POINT HITCH / Type	Limited Cat. 1
3-POINT HITCH / iMatch Quick-Hitch Compatibility	Yes
3-POINT HITCH / Rockshaft Control Type	Select Control
DIMENSIONS / Wheelbase, in. (mm)	57.1 (1,450)
ENGINE / Engine HP (kW) - gross	21.5 (16)
ENGINE / PTO HP (kW) - Hydrostatic transmission	14.9 (11.1)
ENGINE / Rated engine speed, rpm	3,200
ENGINE / Alternator (12 volt, amp)	40
HYDRAULICS / Steering g/m (l/m)	3.5 (13.2)
HYDRAULICS / Implement g/m (l/m)	3.5 (13.2)
HYDRAULICS / Total Capacity g/m (l/m)	7 (26.4)
HYDRAULICS / Lift Capacity (24-in. behind link arms), lb. (kg)	3 758.4 (344)
TRANSMISSION / Std. Transmission; Forward/Reverse	Hydrostatic - 2 range
POWER TAKE-OFF (PTO) / Standard Rear/Mid (RPM)	Rear @ 540; Mid @ 2,100
DIMENSIONS / Outside width rear tires, in. (mm)	R3 - 47.22 (1,200); R4 - 47.32 (1,202)
DIMENSIONS / Approx. Ship Weight, .lb (kg)	R4 - 1433 (650)
Standard R4, optional R3 / Front	18X8.5-10 R4
Standard R4, optional R3 / Rear	26X12-12 R4
OPERATOR STATION / ROPS	Folding
OPERATOR STATION / Optional Cab	No
OPERATOR STATION / Deluxe Lighting Package	No
OPERATOR STATION / Deluxe Seat, Tilt Steering, & Floor Mat	No
OPERATOR STATION / Toolbox	No
OPERATOR STATION / 12V Outlet	No
OPERATOR STATION / Cruise Control 9	No
