Pneumatic Actuators - Scotch Yoke - RG

Name: Pneumatic Actuators - Scotch Yoke - RG
Brand: Flowserve
SKU: flowserve-507

رقم القطعة: flowserve-507

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Automax RG Pneumatic Scotch Yoke Actuators are the cost-effective choice for on/off and inching applications of quarter-turn medium-to-large sized valves in the chemical and general process industries. Features and benefits: - Flowserve's competitive ductile cast iron pneumatic scotch yoke actuator for the chemical and general process industries, where product simplicity and robustness with reduced envelope dimensions are key.

المواصفات

Brand line	Automax
Standards	ISO 9001 and 5211; EN 15714, 60529, 13906, 13445 and 12570; IEC 61508 SC3
Torque Rating Range	up to 248 000 Nm (2.2 million in-lb)
Configurations	Symmetric and canted scotch yoke mechanisms.; Spring return and double acting configurations available (fail open, fail close and fail-in-place capability); Jackscrew, Geared and Hydraulic Manual Operators available on request; Standard or special painting upon request; Standard or customized control panels available on request
Environmental Enclosures	IP 66/67 and IP 66M/67M; ATEX Ex II 2GD; NBR Buna, Viton®, and Fluorosilicone sealing
Pressure Rating	Operating Pressure: 2.5 to 10.3 barg (36.3 to 149.4 psig)
