Flowserve® UZDL Between Bearings Pump - Axially Split, API, Single Case

Name: Flowserve® UZDL Between Bearings Pump - Axially Split, API, Single Case
Brand: Flowserve
SKU: flowserve-674

رقم القطعة: flowserve-674

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

The UZDL is a between bearing, axially split, two-stage pump with a double suction, first-stage impeller. The UZDL is designed for water pipelines, transfer services, firefighting and high-pressure duties. Features and benefits: - Increased uptime made possible by double volute design that minimizes hydraulic radial loads, and virtually eliminates shaft deflection and vibration - Safety and environmental compliance with ISO 21049/API 682 seal chambers - Increased reliability provided by stiff shaft design, which ensures trouble-free operation below the first critical speed - Ease of maintenance due to suction and discharge nozzles that are integrally cast in lower casing half, permitting disassembly without disturbing piping - Centerline - Nozzle loading capability beyond API 610

المواصفات

Brand line	Flowserve
Standards	ISO 13709 / API 610 BB1
Size Range	10" to 24"
Operating Parameters	Flows to M3/H
Flows to	3000 m3/h (13209 gpm)
Temperatures to	200°C (400°F)
Pressures to	64 bar (910 psi)
Heads to	685 m (2250 ft)
