Flowserve HSH Pusher Seal

Name: Flowserve HSH Pusher Seal
Brand: Flowserve
SKU: flowserve-454

رقم القطعة: flowserve-454

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

HSH seals are built for extended reliability in high pressure, high speed and highly viscous services such as mainline crude oil pipeline pumps. HSH seals are balanced, flexible stator cartridge seals with drive mechanisms and seal face geometries engineered for high torque loads and long-term performance. The HSH seal is fully compliant with API 682 Type A requirements. Features and benefits: - Extended service life via high torque-capable anti-rotation lugs that minimize distortion and wear - Greater efficiency from standard distribution ring connected to the seal’s flush port, which improves cooling efficiency by injecting flush flow 360° around seal faces - Reliable high speed operation and improved tolerance of misalignment enabled by flexible stator design with Alloy C-276 spring - Decreased inventory costs and increased design flexibility owing to parts interchangeability between single and dual seal arrangements

المواصفات

Brand line	Flowserve
Standards	API 682
Temperature	-40 to 260°C (-40 to 500°F)
Speed	up to: 46 m/s (150 fps)
Sizes	25.4 to 156 mm (1.000 to 6.125 inch)
Pressure	up to 103 bar (1500 psi)
Arrangement 1 single seal (Common Piping Plans 11, 13, 23, 32, 62)	HSH
Arrangement 2 unpressurized dual wet seal (Common Piping Plans 52)	HSH/HSH
Arrangement 2 unpressurized dual seal with dry running backup (Common Piping Plans 72, 75, 76)	HSH/GSL
Arrangement 3 pressurized dual wet seal (Common Piping Plans 53A, 53B, 53C, 54)	HSH/HSH
