Valtek Mark 100 Linear Globe/Angle Control Valve

Name: Valtek Mark 100 Linear Globe/Angle Control Valve
Brand: Flowserve
SKU: flowserve-651

رقم القطعة: flowserve-651

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

The Valtek® Mark 100 globe control valve delivers exceptional capacity, extra-fine control and easy maintenance — all in a valve designed specifically for use with severe service trims. Based on proven Valtek Mark One control valve technology and built for use in a broad range of industries, the Mark 100 control valve is suited for the most demanding applications. Features and benefits: - Cost-effective performance, as higher Cv capacity allows for smaller valve sizes - Superior process control made possible by long stroke lengths; the position accuracy, repeatability and assured response from the positioner; and the stiff and high-thrust, spring-cylinder actuator - Reduced downtime with the clamped-in seat and self-aligning seat ring - Severe service application versatility provided by a wide variety of noise abatement and anti-cavitation trims

المواصفات

Brand line	Valtek
Size Range	6 to 36
Pressure Class Range	150 to 600
Seating Material	300 series s.s.; 400 series s.s.; alloy 6 & 21 overlay; Monel; Hastelloy; Inconel; Other materials; PTFE soft seat
Standards and certifications	PED Directive 97/23/EC; ATEX QAN Quality Registration; IECEX QAR Quality Registration; SIL Certification; CRN Certification (Canadian Registration); EMC Directive 2004/108/EC; ATEX Directive 94/9/EC; CE Mark; SSOV (FM Safety Shut-off Valve Fuel Service; API 607 Fire Safe
IS0 9001	2008
Severe Service Solutions	Applications requiring noise abatement:; MegaStream; Stealth; Applications requiring cavitation control:; CavControl; ChannelStream; Diamondback
Electronic Certifications for Logix Positioners Mounted on Mark Series Valves	CSA; FM; SIRA; TR CU; INMETRO; TESTSAFE; KOSHA; CCOE
Design and Material Standards for Mark Series Valves	ASTM B16.5; ASTM B16.9; ASTM B16.10; ASTM B16.11; ASTM B16.25; ASTM B16.34; ASTM A (material); ASTM SA (material)
