Name: Pentair Flotec FP4322-08 3/4 HP Thermoplastic Convertible Jet Pump
Brand: Pentair

الوصف

Corrosion resistant convertible jet pumps are constructed of rugged fiberglass-reinforced thermoplastic, and assure years of dependable service. WARRANTY 1 year limited warranty Features and benefits: - Superior performance at depths to water of 100' or less - Fiberglass-reinforced thermoplastic pump housing for the highest corrosion resistance - Ready-to-install 230 volt motor - see manual for 115 volt conversion

المواصفات

Brand line	Flotec
Voltage	230v / 115v , 60 Hz
Horsepower	: 3/4
Body Construction	Thermoplastic
MAXIMUM CAPACITY	15.3 GPM (shallow well setup)
MAXIMUM PRESSURE	52 psi for shallow / 66 psi for 4" deep
AMP DRAW (full load)	6.1 amps on 230v / 12.2 amps on 115v
DISCHARGE PIPE SIZE	: 1" NPT
RECOMMENDED BREAKER	15 amp on 230v / 20 amp on 115v
MAX LIFT	: 25' for shallow setup / 100' for 4" deep setup
MAXIMUM WATER TEMPERATURE	: 140 F (60 C)
SUCTION PIPE SIZE	1-1/4" NPT
FLOW AT 10' LIFT AND 40 PSI	13.8 GPM (shallow well setup) /
PRESSURE SWITCH SETTING	30/50
DRIVE PIPE SIZE	: 1"NPT
