SubDrive SolarPAK Solar-Powered Pumping Package 5SDSP-0.75HP

Franklin Electric

SubDrive SolarPAK Solar-Powered Pumping Package 5SDSP-0.75HP

رقم القطعة: franklin-electric-90040510

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

The System Solution to your solar pumping requirements. Using Franklin quality components, our technical expertise in groundwater pumping, and innovative thinking based on global market inputs, we have developed a rugged, high-output solar-powered pump system which tackles the challenges of remote and harsh environments. No other solar-powered pump system delivers the features, benefits, and reliability of SubDrive SolarPAK in just one package!

المواصفات

HP 60Hz3/4 hp
Frequency60 Hz
PhasesThree-Phase
Amps - Service Factor8.6 A
Volts100 VAC
Voltage Tolerance (%)-10.0% / +10.0%
Wire3-Wire
Thrust Bearing Rating300 lb
MotorSubmersible
Continuous DutyYes
Efficiency Service Factor Load [%]74.80 %
HzDC Input
Input PhaseDC Input
Output PhaseThree-Phase
Input Power Factor1
Input Power Max1200 W
Input Voltage DC45-300 VDC
Lead Retainer MethodLead Jam Nut
Maximum Motor HP (DC Input)3/4 HP
Minimum Output Frequency20 Hz
Maximum Output Frequency60 Hz
Maximum Output Current8.6 A
Output Voltage - 3 Phase (VAC)100 VAC
S.F.1.5
Flow5 gpm
Shut Off459.32 ft
Shut Off 60 Hz541 ft
Stages18
Pressure Sensor IncludedNo
Pressure Transducer IncludedNO
Motor Ambient Temperature Rating Nominal86 °F
Enclosure RatingType 3
Minimum Operating Temperature-13 °F
Maximum Operating Temperature122 °F
Storage Temperature-13° to 144 °F (-25° to 65 °C)
Submersible UseNo
Maximum Fluid Temperature120 °F
Pump Body MaterialAISI 304 Stainless Steel
Discharge Head MaterialStainless Steel
Impeller MaterialAcetal
Motor Bracket MaterialStainless Steel
Check ValveNo
Discharge MaterialStainless Steel AISI 304
Intake Screen MaterialStainless Steel
Thrust BearingKingsbury Type
SealLip Seal Ring
Lead Insulation MaterialXLPE
Diaphragm MaterialNitrile Rubber (NBR)
Flow Switch IncludedYES
Motor Construction DesignSuper Stainless
Motor Fill Solution (Water Soluble / Non Toxic)No
Shaft Slinger MaterialNitrile Rubber (NBR)
Stator/ Motor Shell MaterialStainless Steel
Suction MaterialStainless Steel AISI 304
Shelf Life1.5 year
DischargeThreaded - FNPT
Discharge Diameter1.25 "
Diameter With Cable Guard3.75 "
Motor Length10.64 "
Product Weight with Pack102 lb
Carton Length29.63 "
Carton Width15.81 "
Carton Height23.5 "
Pump Diameter3.75 "
Shaft EndSpline
Component Drive Part Number5870300553
Component Motor Part Number2349029204 GS
Component Pump Part Number90020503
Drinking Water Agency ApprovalsANSI/NSF Standard 61
Electrical Agency ApprovalscUL Listed / UL
Warranty Standard Time12 Mo. from Date of Install / 24 Mo. from Date of Manufacturing
Item #90040510
Model5SDSP-0.75HP
SeriesSubDrive SolarPAK Solar-Powered Pumping Package
Product familySubDrive SolarPAK Solar-Powered Pumping Package
SubTrol Heat SensorNo
Cable Guard MaterialStainless Steel
Pump Length22.6 "
