Borewell Submersible Pump, NEO 60-1512, 1.5 HP, Single Phase, 220 Volts, Size 32 mm

Kirloskar Brothers

Borewell Submersible Pump, NEO 60-1512, 1.5 HP, Single Phase, 220 Volts, Size 32 mm

رقم القطعة: kirloskar-brothers-d11ks01510612529

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Overview Kirloskar NEO 60-1512 Borewell submersible Pump with stainless steel construction, corrosion & abrasion resistant parts, and high discharge capacity, ideal for Domestic and Community Water Supply, Rural Water Supply, Gardening and Small Farm Irrigation, Construction Site, Water Supplies for High Rise Building. The sturdy build and high-efficiency design of these pumps are hallmarks of their long life and assured performance. Features - Wide Voltage Range Operability - The motor is designed to withstand wide voltage variations from 160 - 240 Volts which reduces the chances of motor burning at low voltage - High Efficiency and Energy-saving Design - Innovative design manufactured at state of art plant, delivers optimum efficiency at lower energy consumption resulting in significant cost savings - Dynamically Balanced Rotating Parts - Minimum vibration protects components from damage during the operation, thus ensures consistent performance over longer time period as concentricity is maintained - Longer and Trouble Free Life - High grade engineering materials like Graded Cast Iron Components, Stainless Steel Shaft, Noryl Impellers, Bronze Bushes, Heavy duty Carbon + SS Thrust Plate, 99.9 % pure Copper Winding Wires for longer and trouble free life - Advanced Water Cooled Motors Designs - The motor is filled with potable water, protects from overheating and facilitates smoother and a trouble free operation for the years - Sand Fighter Designs - Innovative Sand Fighter Design restricts the entry of sand in motors,protects bushes of pump and motor thus pumpset perform well in sandy borewells and increase life of pumpset - CED - Cathodic Electro Deposition Coating - CED is the latest coating technology for corrosion resistance with uniform coating, provides 5 times more protection over conventional painting, resulting in longer life. All major CI parts of Kirloskar pumps coming in contact with the water are CED coated - Nationwide Service Network - Easy availability of spares and prompt after sales services through nationwide company Authorised Service Centers

المواصفات

Product SeriesNEO
Pump ModelNEO 60-1512
Pump Type (Installation) Submersible
Pump Type (Application)Borewell Submersible
Power (In HP)01.50
Phase1
Rated Voltage (Volts)220
Frequency (in Hz)50
Speed (rpm)2790
Head Minimum (in m)9
Head Maximum (in m)89
Discharge Minimum15
Discharge Maximum105
Discharge unitlpm
Delivery Size (in mm)32
ImpellerNoryl
Motor BodyStainless Steel
Pump ShaftStainless Steel
SealingOil Seal
Warranty24 Months
Gross Weight (kg)26
Net ContentsPumpset comprising 1 Pump, 1 Motor
Item CodeD11KS01510612529
Manufacturing locationSanand, Gujarat
No. of Stages12
Min. Submergence From Bottom (in mm)2000
