Monobloc Pump, KDS-213N, 2 HP, Single Phase, 240 Volts, Size 80 mm X 80 mm

Name: Monobloc Pump, KDS-213N, 2 HP, Single Phase, 240 Volts, Size 80 mm X 80 mm
Brand: Kirloskar Brothers
SKU: kirloskar-brothers-d11aa02041401031

رقم القطعة: kirloskar-brothers-d11aa02041401031

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Overview Best 2 Hp single phase Kirloskar monobloc pumps comprise a flatter efficiency curve for efficient operation. These centrifugal Monoblock pumps can withstand voltage fluctuations ranging from 230 to 400 volts. The monobloc water pump is perfectly suited for gardening and small farm irrigation, lawn sprinklers, water supply for high rise buildings, domestic and community water supply, water transfer and circulation. Features - Wide Voltage Design - The motor is designed to withstand wide voltage variation which reduces motor burning in case of low/high voltage. - Replaceable Wearing Parts - All wearing parts within the pumps are easily accessible and replaceable which facilitates ease of maintenance thereby extending the life of the pump. - TOP - Thermal Overload Protector - The pump set features a Thermal Overload Protector that protects the motor from overloading, shielding of the motor and associated circuit from the effects of fault current. - CED – Cathodic Electro Deposition - CED is the latest coating technology for corrosion resistance with uniform coating. It provides 5 times more protection over conventional painting, resulting in longer life. All major CI parts of Kirloskar pumps coming in contact with the water are CED coated. - Automatic Air Release - Automatically releases air when the pump starts ensuring swifter and smoother operations, thus eliminating the necessity of operating air release cock. - High Efficiency and Energy Saving Design - Innovative design manufactured at state of art plant, delivers optimum efficiency at lower energy consumption resulting in significant cost savings. - Dynamically Balanced Rotating Parts - Minimum vibration protects components from damage during the operation, thus ensures consistent performance over longer time period as concentricity is maintained. - Designed to Prevent Overloading - Lesser chances of motor burning even if the pump operates at lower head than recommended as motor does not get overload thus ensures substantial saving from maintenance cost and breakdown.

المواصفات

Product Series	KDS
Pump Model	KDS-213N
Pump Type (Installation)	Surface
Pump Type (Application)	Monobloc
Power (In HP)	02.00
Phase	1
Rated Voltage (Volts)	240
Frequency (in Hz)	50
Speed (rpm)	2750
Head Minimum (in m)	6
Head Maximum (in m)	11
Discharge unit	l/s
Suction Size (in mm)	80
Delivery Size (in mm)	80
Impeller	Cast Iron
Delivery Casing	Cast Iron
Motor Body	Cast Iron
Pump Shaft	Carbon Steel
Sealing	MECHANICAL SEAL
Certification/Accreditation	ISI
Warranty	12 Months
Gross Weight (kg)	39
Net Contents	1 Pumpset
Item Code	D11AA02041401031
No. of Stages	1
