Self-priming Pump, V FLOW, 0.5 HP, Single Phase, 240 Volts, Size 25mm X 25mm
رقم القطعة: kirloskar-brothers-t11060051923
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
Overview Kirloskar Domestic Water Pump V Flow comprises a thermal overload protector for motor protection from overloading. This 0.5 HP self-priming pump is suitable for the voltage range 180 to 240 Volts (Single Phase), thus perfectly suited for water supply to overhead tanks in bungalows, gardens, fountains, feed water to RO plants, and lawn sprinklers. Key Features High Suction Lift - The pump has a suction lift capacity of up to 7.5 meters with a high head, facilitating the pumping of water at high volumes for a variety of applications High-Quality Aluminum Motor Body - Special grade aluminum motor body provides high resistance to corrosion, better heat dissipation, and lowers the pump's overall weight for enhanced portability TOP (Thermal Overload Protector) - The pump set features a Thermal Overload Protector that protects the motor from overloading, shielding the motor and associated circuit from fault current Handle to Enhance Grip and Portability - A handle attached to the pump allows the user to carry the pump anywhere, adding to its portability and convenience of use Easy Maintainable Design - Easily maintainable design and better interchangeability of components so that the pump can be serviced even at remote locations by semi-skilled technicians Shielded Ball Bearings - The low-noise pumps are fitted with shielded ball bearings; so, no external lubrication is required throughout the life cycle High Efficiency and Energy Saving Design - Innovative design manufactured at a state-of-the-art, plant ensures optimum efficiency and lower energy consumption resulting in significant cost savings Dynamically Balanced Rotating Parts - Minimum vibrations protect components from damage during operation, resulting in consistent performance as concentration is maintained
المواصفات
| Product Series | V-FLOW |
|---|---|
| Pump Model | V FLOW |
| Pump Type (Installation) | Surface |
| Pump Type (Application) | Self Priming |
| Power (In HP) | 00.50 |
| Phase | 1 |
| Rated Voltage (Volts) | 240 |
| Frequency (in Hz) | 50 |
| Speed (rpm) | 2800 |
| Head Minimum (in m) | 10 |
| Head Maximum (in m) | 34 |
| Discharge Minimum | 729 |
| Discharge Maximum | 2439 |
| Discharge unit | LPH |
| Suction Size (in mm) | 25 |
| Delivery Size (in mm) | 25 |
| Impeller | Brass |
| Delivery Casing | Cast Iron |
| Motor Body | Aluminium |
| Pump Shaft | Carbon Steel |
| Sealing | Mechanical Seal |
| Warranty | 12 Months |
| Gross Weight (kg) | 11 |
| Net Contents | 1 Pumpset |
| Item Code | T11060051923 |
| Manufacturing location | Kaniyur, Tamil Nadu |
| No. of Stages | 1 |
