BAW75T24 Switching power supply and battery charger - Max. 2,7A @ 27,6 VDC

FireClass

BAW75T24 Switching power supply and battery charger - Max. 2,7A @ 27,6 VDC

رقم القطعة: BAW75T24

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

The BAQ is a power supply unit and battery charger to use with appliances that require a regulated voltage of 27,6 V and a maximum current of 5,5 A. Its power output is protected against overload, short-circuit and accidental inversion of the battery polarity. General Features: • Input Voltage: 230 VAC, -15% / +10%, 50/60Hz., 110VAC -15% /+10% 60Hz for BAW Models. • Output Voltage: 27,6VDC, 1% / +1%. • Max. battery size (charge): BAW50T24 = 2 x 12V - 17Ah max. BAW75T24 = 2 x 12V - 17Ah max. BAQ140T24 = 2 x 12V - 17Ah max. • Operating Temperature: -5o to +40oC. • Dimensions (W x H x D) BAW50T24 = 129 x 38 x 98 mm. BAW75T24 = 159 x 38 x 97 mm. BAQ140T24 = 205 x 38 x 98 mm. • Weight: 0.5Kg BAW50T24 and BAW75T24, 0.7Kg BAQ140T24.

المواصفات

FireClass Order Code508.031.753
FireClass RangeFireClass Addressable Range
FireClass CategoryFC600 Panels
FireClass ModelBAW75T24
FireClass FamilyFC600 Accessories
