Eaton 9PX UPS
رقم القطعة: 9PX3000IRTN-L
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
Eaton 9PX UPS
المواصفات
| Special features | Lithium-ion batteriesDouble conversion topologyConstantly monitors power conditions and regulates voltage and frequencyEnergy Star qualified, provides the highest efficiency level to reduce energy and cooling costsInternal bypass allows service continuity in case of UPS faultNext-generation graphical LCD displayNetwork card and rackmounting kit delivered as standardCompatible with Virtual environments (VMware, Hyper-V, Citrix Xen, Redhat)Meter energy consumption (down to the managed outlet groups) |
|---|---|
| Product Name | Eaton 9PX UPS |
| Catalog Number | 9PX3000IRTN-L |
| Model Code | Eaton 9PX 3000i RT2U Netpack Li-Ion |
| Product Length/Depth | 605 mm |
| Product Height | 86.5 mm |
| Product Width | 440 mm |
| Product Weight | 22.9 kg |
| Compliances | CE Marked |
| Source URL | https://www.eaton.com/gb/en-gb/skuPage.9PX3000IRTN-L.html |
| Color | Black/silver |
| Altitude | 3000 m |
| Construction type | 482.6 mm (19 inch) device |
| Voltage type | AC |
| Power consumption | 180 W |
| UPC | 743172105851 |
| Type Of Interface | Other |
| Auto shutdown function | Yes |
| Input connection | C20 |
| Input nominal voltage | 230V default (200/208/220/230/240V) |
| Input voltage - max | 276 V |
| Input voltage - min | 100 V |
| Output frequency | 50/60 Hz |
| Output power factor | 1 |
| Output voltage - max | 240 V |
| Output voltage - min | 200 V |
| Package contents | UPSInput cable(2) IEC-IEC output cablesNetwork Management CardUSB cableSerial cable(2) Supports for tower mounting(2) brackets for 19’ mounting(2) Rack-mounting kitCable locking systemSafety instructionsQuickstart guide |
| Phase (input) | 1 |
| Phase (output) | 1 |
| Potential free switch contact | Yes |
| Primary frequency - min | 40 Hz |
| Primary frequency - max | 70 Hz |
| Runtime at half load | 20.5 min |
| Integrated functionality | Network Mangement |
| Topology | Online/Double-conversion |
| Voltage distortion output (linear load) - max | 3 |
| Wattage | 3000 W |
| Feed type | 1 |
| Runtime at full load | 10 min |
| Relative humidity | 0-96% non-condensing |
| Protocol | SNMP |
| Efficiency at max. load | 94 |
| Rack mounting kit | Yes |
| Battery type | Lithium-ion |
| Communication | USB port (HID compliant)Serial port (RS232)Mini terminal block for remote On/OffMini-terminal block for remote power offMini-terminal block for output relayDry contacts (3 outputs, 1 input, optocoupler, DB9) |
| Warranty | 5 year |
| Rack size | 2U |
| VA rating | 3000 VA |
| Internal bypass | Yes |
| Hot swap power | No |
| Nominal frequency | 50/60 Hz |
| Input frequency range | 40-70 Hz |
| Input power factor | >.99 |
| Receptacle | (8) C13, (2) C19 |
| Number of Outputs C13 | 8 |
| Output waveform | Sine wave |
| Voltage | 230V |
| Output nominal voltage | 230V default (200/208/220/230/240V) |
| Runtime graph | View runtime graph |
| Battery management | Lithium-ion batteries with battery management systemAutomatic recognition of external battery units |
| Battery replacement | Hot-swappable internal batteries and extended battery modules (EBMs) |
| Extended battery capability | Yes |
| Expansion slots | One slot, network card included |
| Ethernet interface | Yes |
| Includes network card | Yes |
| Software compatibility | Eaton Intelligent Power Manager, Eaton Intelligent Power Protector |
| User interface | Multilingual graphical LCD display |
| BTU Rating | Online: 614 |
| Noise level | <40 dB at 1 meter |
| Temperature range | 0° to 40°C (32° to 104°F) |
| Secondary frequency - max | 60 Hz |
| Secondary frequency - min | 50 Hz |
| Efficiency (eco-mode) | 98 |
| Input voltage range | 176-276 V (100-276 V with derating) |
| Max number of battery packs | 4 |
| Output voltage range | 200/208/220/230/240 V +/- 1% |
| Number of Outputs C19 | 2 |
| Number of outputs hardwired | 0 |
| Number of output connections French standard (Type E) | 0 |
| Num of Outputs PC (SCHUKO) | 0 |
| Input cord length | 1.8m |
