Square Plexo box with 7 direct entry membrane glands - IP55 IK07 - 80x80x45 mm - white RAL 9010

Name: Square Plexo box with 7 direct entry membrane glands - IP55 IK07 - 80x80x45 mm - white RAL 9010
Brand: Legrand
SKU: 092013

رقم القطعة: 092013

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Square Plexo box with 7 direct entry membrane glands - IP55 IK07 - 80x80x45 mm - white RAL 9010

Mounting method	Universal
Cover model	Other
Colour	White
RAL-number	9010
Degree of protection (IP)	IP55
Width	94 mm
Depth	52 mm
degree of impact strength (IK)	IK07
Operating / setting temperature (Min-Max)	-25-40 °C
Storage temperature (Min-Max)	-25-70 °C
Halogen free	Yes
Source URL	https://www.legrand.com/ecatalogue/en/catalog/products/square-plexo-box-with-7-direct-entry-membrane-glands-ip55-ik07-80x80x45-mm-white-ral-9010-092013
Legrand Category	Junction box,Junction boxes
Legrand Taxonomy Path	Wiring devices, connected home and building control > Flush mounting boxes, junction boxes, DCL and floor boxes > Junction box
Datasheet URL	https://assets.legrand.com/pim/Certif/LGYBRPFAWZ.PDF
Material	Plastic
Surface protection	Untreated
Label space/information surface	No
Antimicrobial treatment	No
Length	94 mm
Shape	Square
Max. conductor cross section	20 mm²
Equipped with	None
For tube diameter	20 mm
Inlet from the rear	No
Number of inlets	7
Cover attachment	Snapped on
Sealable	No
Circuit integrity	None
With screening	No
Entry membrane gland type	Flexible to cut
Explosion-tested version	No
For Ex-zone gas	None
For Ex-zone dust	None
Connectable	No
Vertical fixing center distance (Min-Max)	47-53 mm
Horizontal fixing center distance (Min-Max)	47-53 mm
Transparent cover	No
Mounting in the soil	No
Mounting under water	No
Type of housing feed-through	Trimmable step membrane
Castable	No
Casting compound included	No
Weatherproof	Yes
