Box Plexo - IP 55 - IK 07 - 155x110x74 - 10 entry membrane glands
رقم القطعة: 092042
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
Box Plexo - IP 55 - IK 07 - 155x110x74 - 10 entry membrane glands
المواصفات
| Mounting method | Universal |
|---|---|
| Cover model | Other |
| Colour | Grey |
| RAL-number | 7035 |
| Degree of protection (IP) | IP55 |
| Width | 130 mm |
| Depth | 81 mm |
| degree of impact strength (IK) | IK07 |
| Operating / setting temperature (Min-Max) | -25-40 °C |
| Storage temperature (Min-Max) | -25-70 °C |
| Halogen free | Yes |
| Source URL | https://www.legrand.com/ecatalogue/en/catalog/products/box-plexo-ip-55-ik-07-155x110x74-10-entry-membrane-glands-092042 |
| Legrand Category | Junction box,Junction boxes,Others |
| Legrand Taxonomy Path | Wiring devices, connected home and building control > Flush mounting boxes, junction boxes, DCL and floor boxes > Junction box |
| Datasheet URL | https://assets.legrand.com/pim/DOCUMENT/LGRP-01611-V02.01-FR.pdf |
| Material | Plastic |
| Surface protection | Untreated |
| Label space/information surface | No |
| Antimicrobial treatment | No |
| Length | 175 mm |
| Shape | Rectangular |
| Max. conductor cross section | 25 mm² |
| Equipped with | None |
| For tube diameter | 25 mm |
| Inlet from the rear | No |
| Number of inlets | 10 |
| Cover attachment | Bayonet latch |
| Sealable | Yes |
| Circuit integrity | None |
| With screening | No |
| Entry membrane gland type | Flexible to cut |
| Explosion-tested version | No |
| For Ex-zone gas | None |
| For Ex-zone dust | None |
| Connectable | No |
| Vertical fixing center distance (Min-Max) | 50-50 mm |
| Horizontal fixing center distance (Min-Max) | 76-82 mm |
| Transparent cover | No |
| Mounting in the soil | No |
| Mounting under water | No |
| Type of housing feed-through | Trimmable step membrane |
| Castable | No |
| Casting compound included | No |
| Weatherproof | Yes |
