C7.1 Marine Propulsion Engine (U.S. EPA Tier 3 / IMO II)

Name: C7.1 Marine Propulsion Engine (U.S. EPA Tier 3 / IMO II)
Brand: Caterpillar
SKU: CAT-15970460

رقم القطعة: CAT-15970460

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

C7.1 Marine Propulsion Engine (U.S. EPA Tier 3 / IMO II)

Bore	105 mm
Stroke	135 mm
Displacement	7.01 l
Model	C7.1
Product Page	https://www.cat.com/en_US/products/new/power-systems/marine-power-systems/commercial-propulsion-engines/15970460.html
Caterpillar Category	Commercial Propulsion Engines
Caterpillar Category Path	Products > Power Systems > Marine Power Systems > Commercial Propulsion Engines > C7.1
Caterpillar Product Family	power-systems
Caterpillar Product Page ID	15970460
Datasheet URL	https://s7d2.scene7.com/is/content/Caterpillar/CM20210209-3fe77-167b3
Height	876 mm
Emissions	U.S. EPA Tier 3, IMO II, RCD II, China II
Width	798 mm
Aspiration	Turbocharged-aftercooled
Length	1095 mm
Speed Range	2300 - 2700 rpm
Configuration	In-line 6, 4-stroke-cycle diesel
Power Range	280 bhp - 425 bhp (209 bkW - 317 bkW)
Governor	Electronic (A5E2 V2 ECM)
Flywheel Housing	SAE No. 03
Refill Capacity	20 L (5.3 gal)
Oil Change Interval	500 hrs
Dry Weight	760 kg
Rotation	Counterclockwise from the flywheel end
Cooling	Heat exchange or keel cooled
