P318 Primary Pulverizer

Caterpillar

P318 Primary Pulverizer

رقم القطعة: CAT-110460

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

P318 Primary Pulverizer

المواصفات

ModelP318 Primary Pulverizer
Product Pagehttps://www.cat.com/en_US/products/new/attachments/pulverizers/primary-pulverizers/110460.html
Caterpillar CategoryPrimary Pulverizers
Caterpillar Category PathProducts > Attachments > Pulverizers > Primary Pulverizers > P318 Primary Pulverizer
Caterpillar Product Familyattachments
Caterpillar Product Page ID110460
Datasheet URLhttps://s7d2.scene7.com/is/content/Caterpillar/CM20220503-5497f-8a539
Height1525 mm
Width790 mm
Length2125 mm
Excavator Minimum18000 kg (39700 lb)
Excavator Maximum25000 kg (55100 lb)
Jaw Depth660 mm
Cycle Time - Open1.6 s
Cycle Time - Close1 s
Crushing Force - Primary Cutter2740 kN
Crushing Force - Tip795 kN
Crushing Force - Primary Tooth1120 kN
Jaw Circuit - Max. Oil Pressure33000 kPa
Jaw Circuit - Max. Oil Flow150 L/min
Cutter Length150 mm
Rotation Circuit - Max. Oil Pressure14000 kPa
Jaw Opening - Maximum1085 mm
Rotation Circuit - Max. Oil Flow40 L/min
Jaw Width - Fixed620 mm
Jaw Width - Moveable335 mm
Weight - Housing, Jaw and Bracket2080 kg
