P324 Primary Pulverizer

Caterpillar

P324 Primary Pulverizer

رقم القطعة: CAT-110540

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

P324 Primary Pulverizer

المواصفات

ModelP324 Primary Pulverizer
Product Pagehttps://www.cat.com/en_US/products/new/attachments/pulverizers/primary-pulverizers/110540.html
Caterpillar CategoryPrimary Pulverizers
Caterpillar Category PathProducts > Attachments > Pulverizers > Primary Pulverizers > P324 Primary Pulverizer
Caterpillar Product Familyattachments
Caterpillar Product Page ID110540
Datasheet URLhttps://s7d2.scene7.com/is/content/Caterpillar/CM20220503-5497f-8a539
Height1700 mm
Width790 mm
Length2305 mm
Excavator Minimum24000 kg (52900 lb)
Excavator Maximum35000 kg (77200 lb)
Jaw Depth730 mm
Cycle Time - Open1.8 s
Cycle Time - Close1.2 s
Crushing Force - Primary Cutter3965 kN
Crushing Force - Tip1175 kN
Crushing Force - Primary Tooth1620 kN
Jaw Circuit - Max. Oil Pressure33000 kPa
Jaw Circuit - Max. Oil Flow225 L/min
Cutter Length200 mm
Rotation Circuit - Max. Oil Pressure14000 kPa
Jaw Opening - Maximum1210 mm
Rotation Circuit - Max. Oil Flow40 L/min
Jaw Width - Fixed640 mm
Jaw Width - Moveable380 mm
Weight - Housing, Jaw and Bracket2755 kg
