404J-E22TA Industrial Diesel Engine

Perkins

404J-E22TA Industrial Diesel Engine

رقم القطعة: 1000024060

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

404J-E22TA Industrial Diesel Engine

المواصفات

Model404J-E22TA
Series400 Series
CategoryIndustrial
Power Rating / Maximum Power55 kW (74 hp)
Power Rating / Maximum Torque270 Nm @ 1600 rpm (199 lb-ft @ 1600 rpm)
Power Rating / Rated Speed2800 rpm
Power Rating / Minimum Power55 kW (74 hp)
Emission Standards / EmissionsEU Stage V, U.S. EPA & CARB Tier 4 Final, Japan MLIT Step 4
General / Number of Cylinders4 inline
General / Cycle4 stroke
General / Bore84 mm (3.3 in)
General / Stroke100 mm (3.9 in)
General / Displacement2.2 l (135 in³)
General / Compression Ratio17.0:1
General / AspirationTurbocharged aftercooled
General / Combustion SystemDirect injection
General / Rotation from Flywheel EndAnti-clockwise
General / Cooling SystemLiquid
Engine Dimensions / Length807 mm (31.7 in)
Engine Dimensions / Width539 mm (21.2 in)
Engine Dimensions / Height757 mm (29.8 in)
Engine Dimensions / Dry Weight242 kg (533.5 lb)
General / AftertreatmentDOC+DPF
