2206D-E13TA Industrial Diesel Engine

Perkins

2206D-E13TA Industrial Diesel Engine

رقم القطعة: 127800

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

2206D-E13TA Industrial Diesel Engine

المواصفات

Model2206C-E13TA
Series2200 Series
CategoryIndustrial
Power Rating / Maximum Power328 kW (440 hp)
Power Rating / Maximum Torque2010 Nm @ 1400 rpm (1482 lb-ft @ 1400 rpm)
Power Rating / Rated Speed1800-2100 rpm
Power Rating / Minimum Power309 kW (414 hp)
Emission Standards / EmissionsEmits equivalent to U.S. EPA Tier 2
General / Number of Cylinders6 vertical in-line
General / Bore130 mm (5.1 in)
General / Stroke157 mm (6.2 in)
General / Displacement12.5 l (762.8 in³)
General / Compression Ratio17.3:1 or 15.8:1
General / AspirationTurbocharged aftercooled
General / Combustion SystemDirect injection (MEUI)
General / Rotation from Flywheel EndAnti-clockwise
General / Cooling SystemLiquid
Engine Dimensions / Length1295 mm (51 in)
Engine Dimensions / Width1054 mm (41 in)
Engine Dimensions / Height1186 mm (47 in)
Engine Dimensions / Dry Weight1138 kg (2509 lb)
General / AftertreatmentNone
General / Total Lubricating Oil Capacity40 l (10.6 gal (US))
Engine Dimensions / Wet Weight1172 kg (2583 lb)
