Q01CPU - Number of I/O points: 1024, number of I/O device points: 2048, program capacity: 14K…

Mitsubishi Electric

Q01CPU - Number of I/O points: 1024, number of I/O device points: 2048, program capacity: 14K…

رقم القطعة: Q01CPU_3889

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Q01CPU - Number of I/O points: 1024, number of I/O device points: 2048, program capacity: 14K…

المواصفات

Basic information / Model nameQ01CPU
Basic information / OverviewNumber of I/O points: 1024, number of I/O device points: 2048, program capacity: 14K steps, basic operation processing speed (LD X0): 100 ns, program memory capacity: 94K bytes, external interface: RS-232, without memory card interface
Basic information / Sales statusDiscontinued
Listed / Model nameQ01CPU 2018/09 Discontinued
Weight0.13 kg
Basic information / Conformance standardUL cUL CE(EMC) CE(RoHS) KC(EMC) LR NK DNV ABS RINA BV
Basic information / Discontinued date2018/09*Please check or inquire it in each overseas sales company site because the sale situation is different depending on each countries.
Basic information / Replacement modelsQ01UCPU Learn more about our products R01CPU Learn more about our products Compare replacement models and specifications
Shock resistanceCompliant with JIS B 3502 and IEC 61131-2 (147 m/s2, 3 times each in 3 directions X, Y, Z)
Operating atmosphereNo corrosive gases
Operating altitude0...2000 m
Installation locationInside a control panel
Overvoltage categoryII or less
Pollution degree2 or less
Operating ambient temperature0...55 ˚C
Storage ambient temperature-25...75 ˚C
Operating ambient humidity5...95 %RH, non-condensing
Storage ambient humidity5...95 %RH, non-condensing
I/O control modeRefresh mode (The direct access input/output is available by specifying the direct access input/output (DX, DY).)
Number of I/O points1024 points (X/Y0...3FF)
Control methodStored program cyclic operation
Listed / OutlineNumber of I/O points: 1024, number of I/O device points: 2048, program capacity: 14K steps, basic operation processing speed (LD X0): 100 ns, program memory capacity: 94K bytes, external interface: RS-232, without memory card interface
Allowable momentary power failure timeThe time differs depending on the power supply module used.
Clock functionYear, month, date, hour, minute, second, and day of week (automatic leap year detection) Accuracy: -3.20...+5.27 s (TYP. +1.98 s)/d at 0 ˚C Accuracy: -2.57...+5.27 s (TYP. +2.22 s)/d at 25 ˚C Accuracy: -11.68...+3.65 s (TYP. -2.64 s)/d at 55 ˚C
Constant scan1...2000 ms (setting is available in increments of 1 ms by parameter)
Programming language / Sequence control languageRelay symbol language, logic symbolic language, MELSAP3 (SFC), MELSAP-L, function block and structured text (ST)
Processing speed / Sequence instruction / LD X0100 ns
Processing speed / Sequence instruction / MOV D0 D1350 ns
Program capacity14K steps (56K bytes)
Memory capacity / Program memory (drive 0)94K bytes
Memory capacity / Standard RAM (drive 3)128K bytes
Memory capacity / Standard ROM (drive 4)94K bytes
Maximum number of storable files / Program memory6
Maximum number of storable files / Standard RAM1
Maximum number of storable files / Standard ROM6
Maximum number of intelligent function module parameters / Initial setting512 parameters
Maximum number of intelligent function module parameters / Refresh256 parameters
Number of I/O device points2048 points (X/Y0...7FF)
No. of device points / Internal relay (M)8192 points (M0...8191) by default (changeable)
No. of device points / Latch relay (L)2048 points (L0...2047) by default (changeable)
No. of device points / Link relay (B)2048 points (B0...7FF) by default (changeable)
No. of device points / Timer (T)512 points (T0...511) by default (changeable) (Low-speed and high-speed timers available) Low-speed or high-speed is specified by an instruction. The measurement unit is set by parameter. (Low-speed timer: 1...1000 ms (in increments of 1 ms), default: 100 ms) (High-speed timer: 0.1...100.0 ms (in increments of 0.1 ms), default: 10.0 ms)
No. of device points / Retentive timer (ST)0 points by default (changeable) (Low-speed and high-speed retentive timers available) Low-speed or high-speed is specified by an instruction. The measurement unit is set by parameter. (Low-speed retentive timer: 1...1000 ms (in increments of 1 ms), default: 100 ms) (High-speed retentive timer: 0.1...100.0 ms (in increments of 0.1 ms), default: 10.0 ms)
No. of device points / Counter (C)Normal counter: 512 points (C0...511) by default (changeable) Interrupt counter: 128 points max. (0 points by default, setting by parameters)
No. of device points / Data register (D)11136 points (D0...11135) by default (changeable)
No. of device points / Link register (W)2048 points (W0...7FF) by default (changeable)
No. of device points / Annunciator (F)1024 points (F0...1023) by default (changeable)
No. of device points / Edge relay (V)1024 points (V0...1023) by default (changeable)
No. of device points / File register (R) / Standard RAM32768 points (R0...32767) (Maximum 65536 points are available by switching blocks.)
No. of device points / File register (ZR) / Standard RAM65536 points (ZR0...65535) (Blocks do not need to be switched.)
No. of device points / Link special relay (SB)1024 points (SB0...3FF) (The number of device points is fixed.)
No. of device points / Link special register (SW)1024 points (SW0...3FF) (The number of device points is fixed.)
No. of device points / Step relay (S)2048 points (S0...127/block) (The number of device points is fixed.)
No. of device points / Pointer (P)300 points (P0...299) (The number of device points is fixed.)
No. of device points / Interrupt pointer (I)128 points (I0...127) (The number of device points is fixed.) (The fixed scan interval for the system interrupt pointer I28 to 31 can be set by parameter.) 2...1000 ms (in increments of 1 ms) Default I28: 100 ms, I29: 40 ms, I30: 20 ms, I31: 10 ms
No. of device points / Special relay (SM)1024 points (SM0...1023) (The number of device points is fixed.)
No. of device points / Special register (SD)1024 points (SD0...1023) (The number of device points is fixed.)
No. of device points / Function input (FX)16 points (FX0...F) (The number of device points is fixed.)
No. of device points / Function output (FY)16 points (FY0...F) (The number of device points is fixed.)
No. of device points / Function register (FD)5 points (FD0...4) (The number of device points is fixed.)
Link direct deviceDevice that directly accesses the link device of a network module Specification format: J□□\X□□, J□□\Y□□, J□□\SB□□, J□□\W□□, J□□\SW□□
Intelligent function module deviceDevice that directly accesses the buffer memory of an intelligent function module Specified form: U...\G...
Latch (data retention during power failure) range2048 points (L0...2047) by default (The latch range can be set for the devices, B, F, V, T, ST, C, D, and W.)
Internal current consumption (5 V DC)0.27 A
External dimensions / Height98 mm
External dimensions / Width27.4 mm
External dimensions / Depth89.3 mm
Vibration resistance / Compliant with .. d IEC 61131-2 / Under intermittent vibration ~62dc24Frequency: 5...8.4 Hz, Half amplitude: 3.5 mm Frequency: 8.4...150 Hz, Constant acceleration: 9.8 m/s2 Sweep count: 10 times each in X, Y, Z directions
Vibration resistance / Compliant with .. and IEC 61131-2 / Under continuous vibration ~d68864Frequency: 5...8.4 Hz, Half amplitude: 1.75 mm Frequency: 8.4...150 Hz, Constant acceleration: 4.9 m/s2
Equipment classClass I
Listed / Large categoriesProgrammable controller CPU
Listed / Medium categoriesBasic model
Memory capacity / CPU shared memory / QCPU standard memory1K bytes
RUN/PAUSE contactOne contact can be set up in X0 to X7FF for each of RUN and PAUSE.
No. of device points / Index register (Z)10 points (Z0...9) (The number of device points is fixed.)
