Q172DEX - Serial absolute synchronous encoder Q171ENC-W8 interface × 2, Tracking input 2 points,…

Mitsubishi Electric

Q172DEX - Serial absolute synchronous encoder Q171ENC-W8 interface × 2, Tracking input 2 points,…

رقم القطعة: Q172DEX_3859

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Q172DEX - Serial absolute synchronous encoder Q171ENC-W8 interface × 2, Tracking input 2 points,…

المواصفات

Basic information / Model nameQ172DEX
Basic information / OverviewSerial absolute synchronous encoder Q171ENC-W8 interface × 2, Tracking input 2 points, With A6BAT (built-in)
Basic information / Sales statusOn sale
Listed / Model nameQ172DEX
Basic information / Conformance standardUL cUL CE(EMC) CE(RoHS) KC(EMC)
Number of occupied I/O points32 points (I/O allocation: intelligent function module, 32 points)
Listed / OutlineSerial absolute synchronous encoder Q171ENC-W8 interface × 2, Tracking input 2 points, With A6BAT (built-in)
Listed / Large categoriesMotion CPU
Listed / Medium categoriesMotion controller
5 V DC internal current consumption [A]0.19
Mass [kg] ~81ac870.15
Exterior dimensions [mm]98.0 (H) × 27.4 (W) × 90.0 (D)
Listed / Small categoriesSynchronous encoder input
Serial absolute synchronous encoder input / Number of modules2 per module
Serial absolute synchronous encoder input / Applicable encoderQ171ENC-W8
Serial absolute synchronous encoder input / Position detection methodAbsolute (ABS) data method
Serial absolute synchronous encoder input / Transmission methodSerial communications (2.5 Mbps)
Serial absolute synchronous encoder input / Backup batteryA6BAT/MR-BAT
Serial absolute synchronous encoder input / Maximum cable length [m]50
Note1. Motion modules cannot be installed in CPU slot and I/O slot 0 to 2 of the main base unit. 2. Install Q172DEX to the main base unit. Do not install to the extension base unit. 3. Compatible model: Q173DSCPU, Q172DSCPU, Q173DCPU, Q172DCPU
Tracking enable input / Number of input points2 points
Tracking enable input / Input methodPositive common/negative common shared type (photocoupler isolation)
Tracking enable input / Rated input voltage/current12 V DC/2 mA, 24 V DC/4 mA
Tracking enable input / Operating voltage range10.2 V DC to 26.4 V DC (ripple ratio 5 % or less)
Tracking enable input / ON voltage/current10 V DC or more/2.0 mA or more
Tracking enable input / OFF voltage/current1.8 V DC or less/0.18 mA or less
Tracking enable input / Response time0.4 ms, 0.6 ms, 1 ms (OFF to ON, ON to OFF) *CPU parameter setting, default 0.4 ms
