Q172EX-S2 - Serial absolute synchronous encoder Q170ENC interface × 2, Tracking input 2 points,…

Mitsubishi Electric

Q172EX-S2 - Serial absolute synchronous encoder Q170ENC interface × 2, Tracking input 2 points,…

رقم القطعة: Q172EX-S2_3906

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

Q172EX-S2 - Serial absolute synchronous encoder Q170ENC interface × 2, Tracking input 2 points,…

المواصفات

Basic information / Model nameQ172EX-S2
Basic information / OverviewSerial absolute synchronous encoder Q170ENC interface × 2, Tracking input 2 points, With A6BAT (built-in)
Basic information / Sales statusDiscontinued
Listed / Model nameQ172EX-S2 2018/09 Discontinued
Basic information / Conformance standardUL cUL CE(EMC) CE(RoHS) KC(EMC)
Basic information / Discontinued date2018/09*Please check or inquire it in each overseas sales company site because the sale situation is different depending on each countries.
Basic information / Replacement modelsQ172DEX Learn more about our products Compare replacement models and specifications
Basic information / Repair support expiration date2025/09
Number of occupied I/O points32 points (I/O allocation: intelligent function module, 32 points)
Listed / OutlineSerial absolute synchronous encoder Q170ENC interface × 2, Tracking input 2 points, With A6BAT (built-in)
Listed / Large categoriesMotion CPU
Listed / Medium categoriesMotion controller
5 V DC internal current consumption [A]0.07
Mass [kg] ~81ac870.15
Exterior dimensions [mm]98.0 (H) × 27.4 (W) × 90.0 (D)
Listed / Small categoriesSynchronous encoder input
Serial absolute synchronous encoder input / Number of modules2 per module
Serial absolute synchronous encoder input / Applicable encoderQ170ENC
Serial absolute synchronous encoder input / Position detection methodAbsolute (ABS) data method
Serial absolute synchronous encoder input / Transmission methodSerial communications (2.5 Mbps)
Serial absolute synchronous encoder input / Backup batteryA6BAT/MR-BAT
Serial absolute synchronous encoder input / Maximum cable length [m]50
Note1. Compatible model: Q173HCPU(-T), Q172HCPU(-T), Q173CPUN(-T), Q172CPUN(-T), Q173CPU, Q172CPU
Tracking enable input / Number of input points2 points
Tracking enable input / Input methodSink/source (photocoupler isolation)
Tracking enable input / Rated input voltage/current12 V DC/2 mA, 24 V DC/4 mA
Tracking enable input / Operating voltage range10.2 V DC to 26.4 V DC (ripple ratio 5 % or less)
Tracking enable input / ON voltage/current10 V DC or more/2.0 mA or more
Tracking enable input / OFF voltage/current1.8 V DC or less/0.18 mA or less
Tracking enable input / Response time0.4 ms, 0.6 ms, 1 ms (OFF to ON, ON to OFF) *CPU parameter setting, default 0.4 ms
Memory for data exchangeNone
