QS0J71GF11-T2 - CC-Link IE Field Network, manager (safety)/local (safety) station

Mitsubishi Electric

QS0J71GF11-T2 - CC-Link IE Field Network, manager (safety)/local (safety) station

رقم القطعة: QS0J71GF11-T2_3458

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

QS0J71GF11-T2 - CC-Link IE Field Network, manager (safety)/local (safety) station

المواصفات

Basic information / Model nameQS0J71GF11-T2
Basic information / OverviewCC-Link IE Field Network, manager (safety)/local (safety) station
Basic information / Sales statusDiscontinued
Listed / Model nameQS0J71GF11-T2 2023/09 Discontinued
Weight0.18 kg
Basic information / Conformance standardUL cUL CE(EMC) CE(Machinery) CE(RoHS) IEC 61508 IEC 62061 EN ISO 13849-1 KC(EMC)
Basic information / End of order date2023/06
Basic information / Discontinued date2023/09*Please check or inquire it in each overseas sales company site because the sale situation is different depending on each countries.
Basic information / Replacement modelsRJ71GN11-T2 Learn more about our products Compare replacement models and specifications
Basic information / Repair support expiration date2030/09
Number of occupied I/O points32 points (I/O assignment: Intelligent 32 points)
Network topologyLine topology, star topology (Coexistence of line topology and star topology is possible.), and ring topology
Maximum station-to-station distance100 m (conforms to ANSI/TIA/EIA-568-B (Category 5e))
Communication methodToken passing method
Listed / OutlineCC-Link IE Field Network, manager (safety)/local (safety) station
Internal current consumption (5 V DC)0.85 A
External dimensions / Height98 mm
External dimensions / Width27.4 mm
External dimensions / Depth115 mm
Listed / Large categoriesSafety network
Listed / Medium categoriesCC-Link IE Field
General specificationsRefer to the general specifications of the CPU module.
Communication speed1 Gbps
Safety communication function / Maximum number of safety connections per stationAsynchronous mode: 31 connections Synchronous mode: 8 connections
Maximum number of link points per network / RX16K points (16384 points, 2K bytes)
Safety communication function / Maximum number of link points per safety connectioninput: 8 words output: 8 words
Maximum number of link points per network / RY16K points (16384 points, 2K bytes)
Communication cableAn Ethernet cable that meets the 1000BASE-T standard: Category 5e or higher (double shielded, STP), straight cable
Maximum number of link points per network / RWr8K points (8192 points, 16K bytes)
Maximum number of link points per network / RWw8K points (8192 points, 16K bytes)
Maximum number of networks239
Maximum number of connectable stations121 stations (manager station: 1, device station: 120)
Overall cable distanceLine topology: 12000 m (when 121 stations are connected) Star topology: Depends on the system configuration Ring topology: 12100 m (when 121 stations are connected)
Maximum number of link points per station / Manager station / RX16K points (16384 points, 2K bytes)
Maximum number of link points per station / Manager station / RY16K points (16384 points, 2K bytes)
Maximum number of link points per station / Manager station / RWr8K points (8192 points, 16K bytes)
Maximum number of link points per station / Manager station / RWw8K points (8192 points, 16K bytes)
Maximum number of link points per station / Local station / RX2K points (2048 points, 256K bytes)
Maximum number of link points per station / Local station / RY2K points (2048 points, 256K bytes)
Maximum number of link points per station / Local station / RWr1K points (1024 points, 2K bytes) 256 points (512 bytes) when communication mode is "High-Speed"
Maximum number of link points per station / Local station / RWw1K points (1024 points, 2K bytes) 256 points (512 bytes) when communication mode is "High-Speed"
Number of cascade connections20 levels maximum
Number of connectable safety stations32 stations
