Atlas Copco

QAS 250 JD Large Diesel Generator

Name: QAS 250 JD Large Diesel Generator
Brand: Atlas Copco
SKU: QAS250JD

رقم القطعة: QAS250JD

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

QAS 250 JD Large Diesel Generator

المواصفات

Model	QAS 250 JD
Series	Large Diesel Generators
Category	Large Diesel Generator
Product Type	diesel-generator-set
Prime Power (kVA)	250 kVA
Frequency	60 Hz
Engine Model	6068HFG06
Engine Displacement	9
Fuel Type	Diesel
Engine Speed	1800
Prime Power (kW)	200 kW
Rating Types	PRIME / STANDBY
Engine Cylinders	6
Engine Aspiration	Turbocharged w/ Intercooler
Alternator Excitation	AREP (auxiliary winding)
Alternator Insulation	Class H
Standby Power (kVA)	275 kVA
Performance / Frequency	60 Hz
Engine / Model	6068HFG06 John Deere
Engine / US EPA Family	MJDXL09.0313
Engine / US EPA Tier	Tier 4 Final
Engine / Displacement	9 L
Engine / Cylinders	6 #
Engine / Aspiration	Turbocharged w/ Intercooler
Engine / Battery Capacity (Cold Cranking Amps)	(2) 1100 A
Emissions Stage	Tier 4 Final
Standby Power (kW)	220 kW
Engine / Continuous Engine Power Output	334 (249) HP (kW)
Engine / Rated Speed	1800 RPM
Engine / Min. Starting Temp (w/o heater)	14 (-10) °F (°C)
Performance / Rated Prime Power @ 400V/50Hz & 480V/60Hz 3Ø	200/250 kW / kVA
Performance / Rated Standby Power @ 400V/50Hz & 480V/60Hz 3Ø	220/275 kW / kVA
Performance / 3Ø Voltage @ 480V 60Hz (Series Star w/Neutral)	480Y/277 V
Performance / Amp Capacity @ 480V 60Hz 3Ø	301 A
Performance / 3Ø Voltage @ 240-208V 60Hz (Parallel Star w/ Neutral)	240Y/139 – 208Y/120 V
Performance / Rated Prime Power @ 240V 3Ø 60Hz	200/250 kW / kVA
Performance / Amp Capacity @ 240V 60Hz 3Ø	600 A
Performance / Rated Prime Power @ 208V 3Ø	173/216 kW / kVA
Performance / Amp Capacity @ 208V 60Hz 3Ø	600 A
Performance / Rated Prime Power 1Ø @ 120-240V 60Hz	144 / 144 kW / kVA
Performance / 1Ø Voltage @ 120-240V 60Hz (Zig-Zag)	240/120 V
Performance / Amp Capacity @ 240V 60Hz 1Ø	600 A
Performance / Amp Capacity @ 120V 60Hz 1Ø	2 x 600 A
Performance / 3Ø Voltage @ 400V 50Hz (Series Star w/Neutral)	- V
Performance / Amp Capacity @ 400V 50Hz 3Ø	- A
Performance / Performance Class (acc. ISO 8528-5:1993)	G2
Performance / Single Step Load Acceptance (0-PRP)	159 (79%) kW (%)
Performance / Sound Pressure Level @ 23’(7 m) @ 75% Load	73 dB(A)
Performance / Alternator (4 Pole, 12 Wire)	LSA 46.2 L6 Leroy Somer
Performance / Excitation system	AREP (auxiliary winding)
Performance / AVR - Automatic Voltage Regulator model	R450 (std) / DVC 550 (parallel option)
Performance / AVR’s AC voltage regulation accuracy	±0.5% (R450) / ±0.25% (DVC 550) %
Performance / Insulation	Class H
Performance / Main Breaker – Rated Current In	800 A
Performance / Power Distribution – Terminal Board	5 Wire (L1, L2, L3, N, Ground)
