John Deere

324 P-Tier Skid Steer

Name: 324 P-Tier Skid Steer
Brand: John Deere
SKU: JOHNDEERE-00Y0T

رقم القطعة: JOHNDEERE-00Y0T

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

324 P-Tier Skid Steer

المواصفات

Displacement	3.3 L (203 cu. in.) 3.3 L (203 cu. in.)
Fuel Tank	79 L (21 gal.)
Model	324 P-Tier
Base Code	00Y0T
Division	construction-equipment
Product Family	skid-steers
Standard	78 L/m (21 gpm)
Net Power (SAE J1349 / ISO 9249)	52.5 kW (70 hp) at 2,500 rpm 52.7 kW (71 hp) at 2,500 rpm
Peak Torque	280 Nm (207 ft.-lb.) at 1,800 rpm 284 Nm (209 ft.-lb.) at 1,800 rpm
Rated Engine Speed	2,500 rpm 2,500 rpm
Torque Rise	34% at 1,800 rpm 36% at 1,800 rpm
2 Speed, High	16.3 km/h (10.1 mph) 17.9 km/h (11.1 mph)
Maximum Axle Torque	6771 Nm (4,994 lb.-ft.) 6771 Nm (4,994 lb.-ft.)
System Pressure at Couplers	23 787 kPa (3,450 psi)
A Length Without Bucket	2.85 m (112.3 in.) (9 ft. 4 in.)
D Height to Top of ROPS	2.06 m (80 in.) (6 ft. 8 in.)
E Height to Hinge Pin	3.20 m (126.0 in.) (10 ft. 6 in.)
F Dump Height With Foundry Bucket	2.59 m (102.1 in.) (8 ft. 6 in.)
With Foundry Bucket	3.46 m (136.3 in.) (11 ft. 4 in.) SKID STEER
With Construction Bucket	3.74 m (147.2 in.) (12 ft. 3 in.)
H Wheelbase	1.12 m (44.2 in.) (3 ft. 8 in.)
J Angle of Departure	28 deg.
L Dump Angle (full lift height)	41 deg.
M Bucket Rollback (ground level)	32 deg.
Tipping Load	2443 kg (5,380 lb.)
SAE Rated Operating Capacity	1221 kg (2,690 lb.)
With Counterweight	1294 kg (2,850 lb.)
Rated Gross Power (ISO 14396)	55.0 kW (74 hp) at 2,500 rpm 55.0 kW (74 hp) at 2,500 rpm
2 Speed, Low	8.7 km/h (5.4 mph) 9.5 km/h (5.9 mph)
Total With High-Flow Option	120 L/m (32 gpm)
High Flow	47 kW (64 hp)
based on a unit with standard equipment, full fuel tank, and	75-kg (165 lb.) operator. For complete details, contact your John Deere dealer.
Base Machine Without Attachment	3496 kg (7,700 lb.)
I Ground Clearance With 12 x 16.5 PR	0.21 m (8.1 in.)
K Front Turn Radius With Foundry Bucket	2.02 m (79.6 in.) (6 ft. 8 in.)
C Width Without Bucket With 12 x 16.5 PR	1.77 m (69.5 in.) (5 ft. 10 in.)
