John Deere

640L-III Cable Skidder

Name: 640L-III Cable Skidder
Brand: John Deere
SKU: JOHNDEERE-1220DW

رقم القطعة: JOHNDEERE-1220DW

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

640L-III Cable Skidder

المواصفات

Diesel Exhaust Fluid (DEF) Tank	19.9 L (5.2 gal.)
Hydraulic Reservoir	123.6 L (32.6 gal.)
Model	640L-III
Base Code	1220DW
Division	forestry-equipment
Product Family	skidders
Width	2192.0 mm (86.3 in.) 2962.4 mm (116.6 in.) 2962.4 mm (116.6 in.)
Height	687.6 mm (27.1 in.) 687.6 mm (27.1 in.) 691.0 mm (27.2 in.)
Range	2 6.38 km/h (3.96 mph)
F Wheelbase	3680 mm (144.8 in.)
Engine Bore and Stroke	106 x 127 mm (4.17 x 5.00 in.) 106 x 127 mm (4.17 x 5.00 in.)
Articulation Angle	45-deg. each direction
Engine	640L-III
John Deere	640L-III Cable Skidder boasts new operator assistance, productivity awareness, and
help make it efficient to operate and reliable to own. The	640L-III is purpose-built to take on
Manufacturer / Model John Deere PowerTech™ PSS	6.8L John Deere PowerTech™ Plus 6.8L
Gross Power	177 kW (237 hp) at 1,800 rpm 163 kW (218 hp) at 1,800 rpm
Gross Torque	1025 Nm (756 ft.-lb.) at 1,600 rpm 979 Nm (722 ft.-lb.) at 1,400 rpm
Engine Displacement	6.8 L (415 cu. in.) 6.8 L (415 cu. in.)
Range 1 (factory settings for each	4.79 km/h (2.97 mph)
Front Axle Oscillation, Stop to Stop	30 deg.
Maximum Displacement	85 cc/rev (5.19 ci/rev)
Standard Fuel Tank	342.2 L (90.4 gal.)
Machine Weight	16 766 kg (36,962 lb.)
Cable Capacity 2-Speed 6000 Winch With	279.5-mm (11 in.) Drum 2-Speed 4000 Winch With 204-mm (8 in.) Drum
15.8 mm (5/8 in.)	119.0 m (390 ft.) 77.4 m (252 ft.)
19.1 mm (3/4 in.)	81.4 m (267 ft.) 54.6 m (177 ft.)
22.2 mm (7/8 in.)	60.3 m (197 ft.) 39.3 m (128 ft.)
25.4 mm (1 in.)	46.0 m (150 ft.) 30.7 m (100 ft.)
Line Pull –	15.8-mm (5/8 in.) Cable Bare Drum at Stall With 2-Speed 6000 Winch Bare Drum at Stall With 2-Speed 4000 Winch
Line Speed –	15.8-mm (5/8 in.) Cable Bare Drum at 1,800 rpm With 2-Speed 6000 or 4000 Winch
Low Speed	18.2 m/min (60 fpm)
High Speed	27.4 m/min (90 fpm)
Tire Size 30.5-32 G Ground Clearance	555 mm (21.8 in.)
A Overall Height	3365 mm (132.5 in.) H Overall Length 7591 mm (298.9 in.)
B Overall Width	3233 mm (127.3 in.) Shipping Dimensions
C Maximum Blade Lift Above Ground	1517 mm (59.7 in.) Tire Size 30.5-32
D Maximum Blade Dig Below Ground	359 mm (14.1 in.) Overall Height 3365 mm (132.5 in.)
E Dozer Blade Width	2192 mm (86.3 in.) Overall Width 3233 mm (127.3 in.)
Optional Dozer Blade Width	2962.4 mm (116.6 in.) Shipping Length 7591 mm (298.9 in.)
