John Deere

2654G Swing Machine

Name: 2654G Swing Machine
Brand: John Deere
SKU: JOHNDEERE-0AE1FF

رقم القطعة: JOHNDEERE-0AE1FF

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

2654G Swing Machine

المواصفات

Fuel Tank	800.0 L (211 gal.)
Model	2654G
Base Code	0AE1FF
Division	forestry-equipment
Product Family	swing-machines
Net Rated Power (ISO 9249)	145 kW (194 hp) at 2,100 rpm 145 kW (194 hp) at 2,100 rpm 145 kW (194 hp) at 2,100 rpm
Off-Level Capacity	70% (35 deg.) 70% (35 deg.) 70% (35 deg.)
Low	2.6 km/h (1.6 mph)
High	3.9 km/h (2.4 mph)
Power Boost	38 000 kPa (5,511 psi)
Cooling System	23.0 L (6.0 gal.)
With full fuel tank;	79-kg (175 lb.) operator, 7-in. riser, side-entry forestry cab, 4547-kg (10,022 lb.) counterweight, 700-mm (28 in.) double-grouser shoes, and
A Maximum Reach	10.16 m (33 ft. 4 in.) 8.94 m (29 ft. 4 in.)
A Maximum Reach at Ground Level	9.91 m (32 ft. 6 in.) 8.64 m (28 ft. 4 in.)
E Minimum Swing Radius	3.23 m (10 ft. 7 in.) 2.82 m (9 ft. 3 in.)
E Undercarriage Length	4.70 m (15 ft. 5 in.) 5.03 m (16 ft. 6 in.) 4.70 m (15 ft. 5 in.) 5.03 m (16 ft. 6 in.)
F Counterweight Clearance	1.40 m (4 ft. 7 in.) 1.40 m (4 ft. 7 in.) 1.40 m (4 ft. 7 in.) 1.40 m (4 ft. 7 in.)
G Upperstructure Width	3.38 m (11 ft. 1 in.) 3.38 m (11 ft. 1 in.) 3.38 m (11 ft. 1 in.) 3.38 m (11 ft. 1 in.)
K Ground Clearance	0.71 m (28 in.) 0.76 m (30 in.) 0.71 m (28 in.) 0.76 m (30 in.)
Swing Speed	10.6 rpm
Manufacturer and Model John Deere PowerTech™ PVS	6.8 L John Deere PowerTech™ Plus 6.8 L John Deere PowerTech Plus 6.8 L
1.06-m³ (1.38 cu. yd.),	1065-mm (42 in.) Bucket 3.40-m (11 ft. 2 in.) Processor Arm
SAE Operating Weight	33 272 kg (73,353 lb.) 33 046 kg (72,853 lb.) 34 317 kg (75,656 lb.) 34 090 kg (75,156 lb.)
Implement Circuits	34 300 kPa (4,975 psi)
Swing Torque	107 869 Nm (79,560 lb.-ft.)
2.95-m (9 ft.	8 in.) Arm; 996-kg (2,195 lb.),
Engine Displacement	6.8 L (415 cu. in.) 6.8 L (415 cu. in.) 6.8 L (415 cu. in.)
2.62 m (8 ft.	7 in.) 2.79-m (9 ft. 2 in.) LC
Maximum Rated Flow x	2 248 L/m (65.5 gpm)
700-mm (28 in.) Double-Grouser Shoes	61.5 kPa (8.92 psi) 56.2 kPa (8.15 psi) 63.5 kPa (9.20 psi) 58.0 kPa (8.41 psi)
Side-Entry Forestry Cab	3085 mm (10 ft. 2 in.)
Rear-Entry Log Loader Cab	4432 mm (14 ft. 6 in.)
Diesel Exhaust Fluid (DEF) Tank (FT4 only)	42.4 L (11.2 gal.)
Engine Crankcase (including filter)	20.0 L (20.6 qt.)
Hydraulic Tank Oil	147.6 L (39.0 gal.)
Rear-Entry Cab	3.76 m (12 ft. 4 in.) 3.76 m (12 ft. 4 in.) 3.96 m (13 ft. 0 in.) 3.96 m (13 ft. 0 in.)
Cab Forward	739 kg (1,630 lb.) 739 kg (1,630 lb.)
2.62-m (8 ft.	7 in.) undercarriage; no attachment included
2.79-m (9 ft.	2 in.) LC Undercarriage 790 kg (1,741 lb.) 790 kg (1,741 lb.)
With standard equipment,	700-mm (28 in.) shoes, 4547-kg (10,022 lb.) counterweight, full fuel tank, and 79-kg (175 lb.) operator
B Maximum Working Depth	6.25 m (20 ft. 6 in.) 4.85 m (15 ft. 11 in.)
C Maximum Working Height	10.64 m (34 ft. 11 in.) 9.88 m (32 ft. 5 in.)
D Maximum Log-Level Height*	7.95 m (26 ft. 1 in.) 7.47 m (24 ft. 6 in.)
F Tail Swing Radius	3.28 m (10 ft. 9 in.) 3.28 m (10 ft. 9 in.)
Side-Entry Cab	3.84 m (12 ft. 7 in.) 3.84 m (12 ft. 7 in.) 3.96 m (13 ft. 0 in.) 3.96 m (13 ft. 0 in.)
B Overall Length	10.29 m (33 ft. 9 in.) 10.29 m (33 ft. 9 in.) 10.34 m (33 ft. 11 in.) 10.34 m (33 ft. 11 in.)
3.1 m (10 ft.)	4.6 m (15 ft.) 6.1 m (20 ft.) 7.6 m (25 ft.)
Undercarriage Pitch	216 mm (8.5 in.) 216 mm (8.5 in.)
Undercarriage	2.62 m (8 ft. 7 in.) 2.79-m (9 ft. 2 in.) LC 2.62 m (8 ft. 7 in.) 2.79-m (9 ft. 2 in.) LC
Rear-Entry Cab (60-in. riser)	671 kg (1,480 lb.) 671 kg (1,480 lb.)
Extra-Heavy Counterweight	1383 kg (3,049 lb.) 1383 kg (3,049 lb.)
C Rear-End Length / Swing Radius	3.20 m (10 ft. 6 in.) 3.20 m (10 ft. 6 in.) 3.20 m (10 ft. 6 in.) 3.20 m (10 ft. 6 in.)
D Distance Between Idler / Sprocket	3.73 m (12 ft. 3 in.) 4.06 m (13 ft. 4 in.) 3.73 m (12 ft. 3 in.) 4.06 m (13 ft. 4 in.)
H Tilted Cab Height (rear-entry cab)	3.76 m (12 ft. 4 in.) 3.76 m (12 ft. 4 in.) 3.76 m (12 ft. 4 in.) 3.76 m (12 ft. 4 in.)
I Track Width With	700-mm (28 in.) 0.71 m (28 in.) 0.71 m (28 in.) 0.71 m (28 in.) 0.71 m (28 in.)
J Center of Sprocket to Center of	2.62 m (8 ft. 7 in.) 2.79 m (9 ft. 2 in.) 2.62 m (8 ft. 7 in.) 2.79 m (9 ft. 2 in.)
L Undercarriage Width With	3.33 m (10 ft. 11 in.) 3.53 m (11 ft. 7 in.) 3.33 m (10 ft. 11 in.) 3.53 m (11 ft. 7 in.)
660-mm (26 in.) or	700-mm
Lift Capacity — 2654G Road Builder with	2.62-m (8 ft. 7 in.) undercarriage, 700-mm (28 in.) shoes, and standard counterweight; bare pin
Lift Capacity — 2654G Processor with	2.62-m (8 ft. 7 in.) undercarriage, 700-mm (28 in.) shoes, and standard counterweight; bare pin
