John Deere

1070G Wheeled Harvester

Name: 1070G Wheeled Harvester
Brand: John Deere
SKU: JOHNDEERE-0480WJ

رقم القطعة: JOHNDEERE-0480WJ

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

1070G Wheeled Harvester

المواصفات

Gear	1 0–7.5 km/h (0–4.7 mph)
Front	34 in. or 26.5 in. 22.5 in.
Rear	34 in. 26.5 in.
Total	24 L (6.3 gal.)
Model	1070G
Base Code	0480WJ
Division	forestry-equipment
Product Family	wheeled-harvesters
Net Peak Torque	850 Nm (627 lb.-ft.) at 1,400–1,500 rpm
Hydraulic Tank	160 L (42.3 gal.)
Transport length	11 435 mm (37.52 ft.) 11 424 mm (37.48 ft.)
Transport height	3708 mm (12.17 ft.) 3730 mm (12.24 ft.)
Fuel Tank Capacity	300 L (79.3 gal.)
Alternator	150 A (28 volt)
Slewing Angle	220 deg.
Rotating Angle	160 deg.
B + C Wheelbase	3700 mm (12.14 ft.) 3700 mm (12.14 ft.)
Maximum Power	136 kW (182 hp) at 1,600–2,000 rpm
Usable	13 L (3.4 gal.)
Pump Capacities	160 cm (9.7 cu. in.)
Working Pressure	24 MPa (3,480 psi) / 28 MPa (4,060 psi)
Maximum Reach Lengths (head included)	8.6 m (28.2 ft.) / 10.0 m (32.8 ft.) / 10.8 m (35.5 ft.)
Tilt Angle, Forward / Back	+28 / –14 deg.
Sideways Tilt	17 deg.
Forward and Backward Tilt	10 deg.
A Length	6723 mm (22.06 ft.) 6990 mm (22.93 ft.)
B Front Axle — Middle Joint	1850 mm (6.07 ft.) 1850 mm (6.07 ft.)
C Rear Axle — Middle Joint	1850 mm (6.07 ft.) 1850 mm (6.07 ft.)
600-Series Tires Min.	2600 mm (8.53 ft.) Min. 2663 mm (8.74 ft.)
650-Series Tires Min.	2710 mm (8.89 ft.) Min. 2710 mm (8.89 ft.)
710-Series Tires Min.	2790 mm (9.15 ft.) Min. 2823 mm (9.26 ft.)
Outer Turning Radius – 710-Series Tires	5815 mm (19.08 ft.) 6017 mm (19.74 ft.)
Inner Turning Radius – 710-Series Tires	3080 mm (10.10 ft.) 3247 mm (10.65 ft.)
E Ground Clearance, Middle Joint	570 mm (22.4 in.) 590 mm (23.2 in.)
Minimum Machine Weight With Harvester Head	15 200 kg (33,510 lb.) 16 000 kg (35,274 lb.)
