ZV5400
المواصفات
| Machine weight (lbs) | 18200 |
|---|---|
| Machine weight (kg) | 8300 |
| Stroke X/Y/Z (in) | 44.1/22.0/22.0 |
| Stroke X/Y/Z (mm) | 1,120/560/560 |
| Spindle taper type | BT/CAT |
| Spindle speed (min-1) | 100-12,000 |
| Spindle motor output (kW) | 18.5/15 |
| Fast forwarding speed (m/min) | 6,000 (2,3622.2 inches) |
| Number of tools stored (pcs) | 25 |
| Max tool length (in) | 13.4 |
| Max tool length (mm) | 340 |
| Max tool diameter (in) | 3.5 (with adjacent tool) or 7.1 (without adjacent tool) |
| Max tool diameter (mm) | 90 (with adjacent tool) or 180 (without adjacent tool) |
| Control unit (maker) | FANUC 18iMB |
| Machine mass (kg) | 8300 |
| Machine mass (lbs) | 18200 |
| Spindle taper type (representative) | BT/CAT |
| Max spindle speed (min-1) | 12000 |
| Machine height (mm) | 2910 |
| Machine height (in) | 114.6 |
| Required floor space (mm) | 3,096 x 3,290 |
| Required floor space (in) | 121.9 x 129.5 |
