NX400
رقم القطعة: KOMATSU-NX400
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
NX400
المواصفات
| Machine weight (lbs) | 50706 |
|---|---|
| Machine weight (kg) | 23000 |
| Stroke X/Y/Z (in) | 23.6/23.6/27.6 |
| Stroke X/Y/Z (mm) | 600/600/700 |
| Spindle taper type | HSK-A63 |
| Spindle speed (min-1) | 100-12,000 |
| Spindle motor output (kW) | 11/7.5 |
| Fast forwarding speed (m/min) | 60 |
| Number of tools stored (pcs) | 39 |
| Max tool length (in) | 11.8 |
| Max tool length (mm) | 300 |
| Max tool diameter (in) | 9.8 |
| Max tool diameter (mm) | 250 |
| Control unit (maker) | FANUC |
| Machine size (W x D x H) (mm) | 3,000 x 6,000 x 3,200 |
| Machine size (W x D x H) (in) | 118.1 x 236.2 x 126.0 |
| Machine mass (kg) | 23000 |
| Machine mass (lbs) | 50706 |
| Spindle taper type (representative) | HSK-A63 |
| Max spindle speed (min-1) | 12000 |
| Number of storage bottles (standard) (pcs) | 39 |
