14CM10
رقم القطعة: KOMATSU-14CM10
لا يعرض أي بائع سعرًا لهذا المنتج بعد.
للطلب والدفع استخدم تطبيق ENG.
الوصف
14CM10
المواصفات
| Ground clearance (in) | 6 |
|---|---|
| Ground clearance (mm) | 150 |
| Conveyor width (in) | 30 |
| Conveyor width (mm) | 762 |
| Tram speed (m/min) | 5 - 26 |
| Ground pressure (kPa) | 160 |
| Ground pressure (psi) | 23 |
| Weight (kg) | 45 360 |
| Weight (lbs) | 100,000 |
| Cutter head diameter (in) | 30 |
| Maximum cutting height (in) | 122 |
| Maximum cutting height (mm) | 3 099 |
| Minimum cutting height (in) | 38 |
| Minimum cutting height (mm) | 965 |
| Total power (HP) | 665 |
| Total power (kW) | 496 |
| Cutter head design | Ripperveyor |
| Cutter head diameter (mm) | 762 |
| Tram speed (ft/min) | 15 - 85 |
| Dust collector (kW) | 13 |
| Cutter (HP) | 165 |
| Dust collector (HP) | 18 |
| Cutter (kW) | 123 |
| Pump (HP) | 40 |
| Pump (kW) | 30 |
| Gathering head (kW) | 50 |
| Gathering head (HP) | 67 |
| Traction (HP) | 80 |
| Traction (kW) | 60 |
| General footnote | Total power does not include dust collector fan |
| Recommended operating range (mm) | 965 - 1 220 |
| Recommended operating range (in) | 38 - 48 |
