VR66C Vibratory Roller Compact Equipment Attachment

Name: VR66C Vibratory Roller Compact Equipment Attachment
Brand: John Deere
SKU: JOHNDEERE-7791T

رقم القطعة: JOHNDEERE-7791T

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

VR66C Vibratory Roller Compact Equipment Attachment

Overall Length	99 cm (39 in.)
Model	VR66C Vibratory Roller
Base Code	7791T
Division	construction-equipment
Product Family	construction-attachments
Overall width	1.8 m (72 in.)
Overall Height	79 cm (31 in.)
325G	
P-Tier Large Frames	
P-Tier Small Frames	 WT
316 P-Tier 317 P-Tier 318 P-Tier 320G	 WT
Drum Width	1.7 m (66 in.)
Drum Diameter / Smooth	61.cm (24 in.)
Drum Diameter / Sheepsfoot (without pads)	51 cm (20 in.)
Drum Diameter / Drum Oscillation	±15 deg.
Drum Diameter / Dynamic Force	3538 kg (7,800 lbf)
Vibrations per Minute / Range	41–95 L/min. (11–25 gpm)
Vibrations per Minute / Optimum Performance	75.7 L/min. (20 gpm)
Operating Weight / Smooth Drum	975 kg (2,150 lb.)
Operating Weight / Sheepsfoot Drum	945 kg (2,085 lb.)
Vehicle Compatibility / Smooth Drum	316 P-Tier † , 318 P-Tier † , 320G † , 324G † , 330 P-Tier, and 334 P-Tier SSLs; 317 P-Tier † , 325G,
Vehicle Compatibility / Sheepsfoot Drum	331 P-Tier, 333 P-Tier, and 335 P-Tier CTLs 316 P-Tier † , 318 P-Tier † , 320G † , 324G † , 330 * Requires skid-steer-style Quik-Tatch coupler for operation. / † Requires additional weights.
