338 Small Square Baler

Name: 338 Small Square Baler
Brand: John Deere
SKU: JOHNDEERE-6241E

رقم القطعة: JOHNDEERE-6241E

لا يعرض أي بائع سعرًا لهذا المنتج بعد.

للطلب والدفع استخدم تطبيق ENG.

الوصف

338 Small Square Baler

Model	338
Base Code	6241E
Division	hay-and-forage-equipment
Product Family	balers
BALE SIZE / Cross section	14x18 in. (36x46 cm)
BALE SIZE / Length	12 to 50 in. (31 to 127 cm)
PICKUP / Width inside	64 in. (1.6 m)
PICKUP / Width of flares	74 in. (1.9 m)
PICKUP / Number of teeth	156 on six bars
PICKUP / Height adjustment	Crank (hydraulic, opt.)
PICKUP / Height adjustment range	5 in. (13 cm)
PICKUP / Cylinder diameter	12 in. (31 cm)
AUGER / Diameter	16 in. (41 cm)
AUGER / Length	61 in. (1.5 m)
AUGER / FEEDING OPENING	289 sq. in. (0.19 m 2 )
AUGER / Stroke	30 in. (76 cm)
AUGER / Normal speed (under load)	80 strokes/min.
AUGER / Bottom rollers	Sealed ball-bearing rollers
AUGER / Top rollers	Wear pads (top)
FLYWHEEL / Diameter	27 in. (69 cm)
FLYWHEEL / Weight	227 lb. (103 kg)
COMPRESSION CHAMBER / Length	46 in. (1.2 m)
TIRES / Right	26x12.00-12, 4PR
TIRES / Left	11Lx14, 6PR
DIMENSIONS / Height (maximum)	67 in. (1.7 m)
DIMENSIONS / Width	108 in. (2.7 m)
DIMENSIONS / Length (with bale chute and 3-joint PTO)	227 in. (5.8 m)
DIMENSIONS / Length (without tongue and bale chute)	134 in. (3.4 m)
DIMENSIONS / DRIVELINE	Cat. 4
DIMENSIONS / PTO SPEED	540 rpm
DIMENSIONS / MIN REQUIRED PTO HORSEPOWER	35 hp
DIMENSIONS / Gears	Steel-cut, enclosed
DIMENSIONS / Capacity (SAE 90 SCLO)	4 U.S. qt. (3.8 L)
WEIGHT / Twine (min.)	2,805 lb. (1272 kg)
WEIGHT / Twine (max.)	2,972 lb. (1348 kg)
WEIGHT / Wire (min.)	2,835 lb. (1286 kg)
WEIGHT / Wire (max.)	3,002 lb. (1362 kg)
